RE Audio RFX10D4

10" Dual 4 ohm RFX Series Subwoofer

RE Audio
Shop all RE Audio
Product videos
highlight-star-icon

10" Dual 4 ohm RFX Series Subwoofer • RMS: 190 watts • Kraft Pulp Cone • Santoprene Rubber Surround • Peak: 2000 watts

Learn more about the rfx10d4

We apologize

This item has been discontinued


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

NSP35 main

NVX NSP35

200W Peak (70W RMS) 3.5" N-Series 2 Way Coaxial Car Speakers

55
-16.67%

$49.99

List price $59.99

JL Audio C2-600cw (Sold Individually)

60W RMS 6” C2 Series Component 4-ohm Car Midwoofer

$159.99

Product Highlights


10" Dual 4 ohm RFX Series Subwoofer • RMS: 190 watts • Kraft Pulp Cone • Santoprene Rubber Surround • Peak: 2000 watts

Description


RE Audio brand icon

Authorized dealer

Product Features:
  • 10" Dual 4 ohm RFX Series Subwoofer
  • Power Handling:
    • RMS: 190 watts
  • Impedance: Dual 4 ohm
  • Kraft Pulp Cone
  • Santoprene Rubber Surround
  • Pressed steel basket
  • FEA Optimized motor structure
  • Linear Conex spiders
  • Rubber gasket
  • High temperature 8-layer copper voice coil
  • Powerful, Double Stack Magnet
  • Sensitivity: 84.7 dB
  • Mounting Depth: 5-1/2"
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Subwoofer Wiring Guide


Wiring Guide to Wire 1 RE Audio RFX10D4 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 RE Audio RFX10D4 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 RE Audio RFX10D4 Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 RE Audio RFX10D4 Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95


Best selling similar products

SQW104 small

NVX SQW104

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.23"
• Sensitivity: 83 dB

$249.99

List price $299.99

10TW3-D4 small

JL Audio 10TW3-D4

• RMS Power: 400 watts
• Polymer/Mica Composite Cone
• Rubber Surround
• Impedance: Dual 4 ohm
• Mount depth: 3.25"
• Sensitivity: 82.10 dB

(29)

$519.99

List price $519.99

HS102D small

Cerwin Vega HS102D

• Peak Power: 800 watts
• RMS Power: 200 watts
• Impedance: Dual 2 ohm
• Polypropylene Cone
• Treated Foam Surround
• Mount depth: 3.54"
• Sensitivity: 83.1 dB

(4)

$99.99

List price $119.99

SPK-10S2 small

AudioControl SPK-10S2

• Peak Power: 700 watts
• RMS Power: 500 watts
• Impedance: Single 2 ohm
• Paper Fiber with Mica Coating Cone
• Rubber Surround
• Mount depth: 5.32"
• Sensitivity: 82.2488 dB

$209.00

List price $229.00

TN10-04 small

MTX TN10-04

• Peak Power: 300 watts
• RMS Power: 150 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 4-11/16"
• Sensitivity: 84.9 dB

(15)

$79.95

List price $59.95

10W0v3-4 small

JL Audio 10W0v3-4

• RMS Power: 300 watts
• Impedance: Single 4 ohm
• Mount depth: 4.90"
• Sensitivity: 84.07 dB

(68)

$139.99

List price $139.99

SPK-10S4 small

AudioControl SPK-10S4

• RMS Power: 700 watts
• Impedance: Single 4 ohm
• Paper Fiber with Mica Coating Cone
• Rubber Surround
• Mount depth: 5.32"
• Sensitivity: 83.7199 dB

$209.00

List price $229.00

TS-D10LS4 small

Pioneer TS-D10LS4

• Peak Power: 1300 watts
• RMS Power: 350 watts
• Impedance: Single 4 ohm
• IMPP - Aramid Fiber and Carbon Fiber Cone
• Rubber Surround
• Mount depth: 3-1/4"
• Sensitivity: 76 dB

$153.00

List price $260.00

VCW104v3 small

NVX VCW104 Version 3 (VCW104v3)

• Peak Power: 2000 watts
• RMS Power: 1000 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 6.30"
• Sensitivity: 82 dB (1W/1m)

(71)

$169.99

List price $203.99

5510-44 small

MTX 5510-44

• Peak Power: 800 watts
• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 5.625"
• Sensitivity: 83.5 dB

(1)

$189.95

List price $159.95

Specifications & Details


Subwoofer Specifications
Series
RFX Series
Subwoofer Size
10"
RMS Power Handling
190 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Sensitivity
84.7 dB
Xmax (millimeters)
12 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Kraft Pulp
Woofer Surround
Rubber
Magnet Structure
Double Stacked
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.4 cubic feet
Maximum Sealed Box Volume
0.6 cubic feet
Minimum Ported Box Volume
0.7 cubic feet
Maximum Ported Box Volume
1.1 cubic feet
Top-Mount Depth (Mounting Depth)
5-1/2"
Cutout Diameter
9-5/16"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
21.5 Hz
Equivalent Compliance (Vas)
27.1 liters
Total Speaker Q Value (Qts)
0.34
Electrical Q Value (Qes)
.039
Mechanical Q Value (Qms)
4.37
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

RFX10D4

Weight:

12.00lbs

Internal SKU:

rfx10d4

Internal Product ID:

43760

Product and How-to Videos


  • RE Audio RFX Car Sub | Subwoofer Review
  • RE Audio New Product Line Overview | CES 2015
  • Car Subwoofer Size Buying Guide | What Size of Sub Should I Get?

Customer Ratings & Reviews


RE Audio RFX10D4 thumbnail image

5 star
67%
4 star
0%
3 star
33%
2 star
0%
1 star
0%



Durability
3.4
Value
5
Features
4
Design
5
Usability
4.7

Customer Reviews

Sort by:

Loading...

Solid Performer

I have this paired with a 300 watt amp, sealed and it sounds great. Some of the smoothest bass I've ever heard, Definitely recommend

By slick on January 20, 2013

3 found this helpful


No Beast Here

I bought this sub to pair with a 350.1 sound ordinance amp from crutch. wanted tight and clean so sealed it in a .7 box. Both sub and box from sonic. I really love this sub don't get me wrong. the bass is clean and tight although it gets overwhelmed on double bass drum metal songs. the best i've heard so I'm upgrading to the 300rms as a replacement. It does put out some big bass for a 10 190 rms, but I thought is was built for brutality. BS and I'm calling it. Unless the amp is severely underrated. Settings, 75% gain, head unit amp at Low Power. Sub lever at 50%, and bass boost at 75%. Well never the less. the sub started making a popping noise at peak burst initially. Now it pops on most songs i play and i have to turn the bass down instead of up. Definitely a great sub and going with the re srx as i said, but if you're planning on giving more than 200 watts in sealed enclosure, think again. Sonic is replacing this one for the upgrage w/o much hassle and discounted return shipping. They have come a long way. Thanks look forward to my 300 RMS RE SRX.

By slick on June 26, 2012

3 found this helpful


Great sub for small box applications

Great sub for small box applications, get pretty loud for only 190 watts RMS. Great price. RE is always solid.

By Josh on January 21, 2013
