PowerBass ASA-400.2

800W Max, 2-Channel Amplifier ASA400.2

PowerBass
Shop all PowerBass
Product videos
highlight-star-icon

800 watts Max, Class A/B 2-Channel Amplifier • 200 watts x 2 chan. @ 2 ohm • 400 watts x 1 chan. @ 4 ohm Bridged • MOSFET Power Supply • Variable High Pass and Low Pass Crossover • Soft Delay Remote Turn On/Off Circuit • Self Diagnostic Protection Circuit, LED indicates Impedance Overload, Speaker Short Circuit, Thermal Overheating, and DC Output

Learn more about the asa4002

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

asa4002x thumbnail

PowerBass ASA 400.2x

OUR PRICE: $99.99

View item

Loading...
99-5700 main

Metra 99-5700 Dash Kit

Install a new Single-DIN car stereo in select 1975-2000 vehicles from Ford, Mercury, Mazda

5
-12.50%

$27.99

List price $31.99

70-1770 main

Metra 70-1770 Wiring Harness

Install a new car stereo in select 1986-2004 vehicles from Ford, Mercury, Mazda

22
-14.31%

$5.99

List price $6.99

95-5704 main

Metra 95-5704 Dash Kit

Install a new Double-DIN car stereo in select 1992-1996 E Series

1
-38.72%

$37.99

List price $61.99

Limited time!
46CSC684 main

Kicker CSC68 (46CSC684)

450W Peak (150W RMS) 6x8” CS Series 2 Way Coaxial 4-ohm Speakers

11
-33.36%

$79.96

List price $119.99

Limited time!
CELEBRITY 100 main

JBL CELEBRITY 100 (JBLCELEBRITY100)

Single DIN Digital Audio Receiver with Bluetooth

2
-42.89%

$39.95

List price $69.95

Cerwin-Vega CV7BM

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth

12

$109.00

List price $109.99

Limited time!

JBL Stage2 624 (STAGE2624)

480W Peak (80W RMS) 6.5" Stage2 Series 2 Way Coaxial 4-ohm Speakers

7
-42.02%

$57.95

List price $99.95

Pioneer TS-A6881F

700W Peak (160W RMS) 6x8" A-Series 4-way 4-ohm Coaxial Car Speakers

5
-40.01%

$65.99

List price $110.00

Product Highlights


800 watts Max, Class A/B 2-Channel Amplifier • 200 watts x 2 chan. @ 2 ohm • 400 watts x 1 chan. @ 4 ohm Bridged • MOSFET Power Supply • Variable High Pass and Low Pass Crossover • Soft Delay Remote Turn On/Off Circuit • Self Diagnostic Protection Circuit, LED indicates Impedance Overload, Speaker Short Circuit, Thermal Overheating, and DC Output

Description


PowerBass brand icon

Authorized dealer

  • 800 watts Max, Class A/B 2-Channel Amplifier
  • RMS Power Ratings:
    • 4 ohm: 100 watts x 2 chan.
    • 2 ohm: 200 watts x 2 chan.
    • 4 ohm Bridged: 400 watts x 1 chan.
  • MOSFET Power Supply
  • Low Profile Aluminum Finned Heatsink
  • Variable High Pass and Low Pass Crossover
  • 12 dB per Octave Crossover Slope
  • Frequency Response: 20 - 22,000 Hz
  • Soft Delay Remote Turn On/Off Circuit
  • 0 - 18 dB Bass Boost
  • Self Diagnostic Protection Circuit, LED indicates Impedance Overload, Speaker Short Circuit, Thermal Overheating, and DC Output
  • Variable Gain Control
  • Optional Remote Gain Control
  • Low Level Line Inputs and Outputs
  • Dimensions: 10.2"L x 9.3"W x 1.9"H
  • 8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 1-year SonicElectronix.com warranty

Product history:

PowerBass ASA400.2x thumbnail
(newest, current model)
PowerBass ASA-400.2 thumbnail
(previous model, replaced by PowerBass ASA 400.2x)

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 2 channel
RMS Power @ 2 ohms
200 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
400 watts x 1 channel
Amplifier Specifications
Number of Channels
2-Channel
Total Peak Power Output
800 watts
Total RMS Power Output
400 watts
Maximum Input Gauge Size
8 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
.05%
Speaker Level Inputs
No
Preamp Outputs
Yes
High-Pass Crossover Frequency
40 - 250 Hz
Low-Pass Crossover Frequency
40 - 250 Hz
Signal-to-Noise Ratio
94 dB
Bass Boost
0 - 18 dB
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
15A x 2

Item Details


Manufacturer:

Model Number:

ASA-400.2

Weight:

7.50lbs

Internal SKU:

asa4002

Internal Product ID:

7020

Product and How-to Videos


Customer Ratings & Reviews


PowerBass ASA-400.2 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
4
Usability
5

Customer Reviews

Sort by:

Loading...

.

I am running this amp bridged at 400 watts (rms) and it sounds great and does not get super hot like some other amps. It is pretty compact and it looks nice aswell. My only complaint would be that it wouldnt fit the kicker power and ground wires untill i trimmed about half off. (understandable though, the wiring is really wide/thick)

overall, great amp, and i would reccomend it to anyone looking for a compact, nice looking, amp to run thier sub(s).

By josh on June 28, 2007

12 found this helpful


Best 800w amp I've ever heard

This amp is great and has taken my abuse for more than 3 years.
Everyday use and still clear under full power use. I had it running two 10" kickers until it blew them, and now im running two 12" pioneer subs.
Not the most powerful, but perfect for a stock alternator.

By Jonathan G on April 16, 2013
