Soundstream PCO.12

350W 12" Picasso Series Single 4 Ohm Subwoofer

Product videos
highlight-star-icon

• RMS Power: 350W
• Injection Molded Polypropylene Cone
• NBR Rubber Surround • Overcast Stitched Cones
• Frame Voice Coil Venting

Learn more about the pco12

We apologize

This item has been discontinued


Loading...
Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

REF507CF main

Infinity REF507CF (INFSPKRF507CFUS)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

-12.00%

$219.95

List price $249.95

DMDX5 main

Diamond Audio DMDX5

240W Peak (80W RMS) 5" DMD Series 2-Way Cocentric Coaxial 4-ohm Speakers

DB5252 main

Polk Audio DB5252 (DB 5252)

600W Peak (200W RMS) 5.25” DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

4

$200.00

List price $209.99

DSK 130.3 main

Hertz DSK 130.3

240W Peak (120W RMS) 5.25” Dieci Series 2-way 4-ohm Component Speaker System

-13.05%

$199.99

List price $230.00

Limited time!
46CSC54 main

Kicker CSC5 (46CSC54)

450W Peak (150W RMS) 5.25” CS Series 2 Way Coaxial 4-ohm Speakers

5
-33.36%

$79.96

List price $119.99

DB522 main

Polk Audio DB522 (DB 522)

600W Peak (200W RMS) 5.25" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

13
-9.08%

$100.00

List price $109.99

43DSC504 main

Kicker DSC50 (43DSC504)

400W Peak (100W RMS) 5.25" DS Series 2-way 4-ohm Coaxial Car Speakers (DSC504)

17
-11.77%

$74.99

List price $84.99

VSP525 main

NVX VSP525

480W Peak (160W RMS) 5.25" V-Series 2 Way Coaxial Car Speakers

23
-16.67%

$79.99

List price $95.99

Product Highlights


• RMS Power: 350W
• Injection Molded Polypropylene Cone
• NBR Rubber Surround • Overcast Stitched Cones
• Frame Voice Coil Venting

Description


Soundstream brand icon

Authorized dealer

General Features:

  • 12" Picasso Series Single 4 Ohm Subwoofer
  • Power Handling:
    • RMS: 350 watts
  • Injection Molded Polypropylene Cone
  • NBR Rubber Surround
  • 2" frame vented voice coil
  • Sensitivity: 88.41 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Soundstream PCO.12 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Soundstream PCO.12 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Soundstream PCO.12 Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 Soundstream PCO.12 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

Marine Club 12 small

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

VCW124v3 small

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

SQW124 small

NVX SQW124

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.51"
• Sensitivity: 84 dB

$299.99

List price $359.99

Specifications & Details


Subwoofer Specifications
Series
Picasso Series
Subwoofer Size
12"
RMS Power Handling
350 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2"
Sensitivity
88.41 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Injection Molded Polypropylene
Woofer Surround
Nitrile Butadiene Rubber NBR
Magnet Structure
Single Stacked
Subwoofer Grille
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
1 cubic feet
Optimum Ported Box Volume
1.75 cubic feet
Top-Mount Depth (Mounting Depth)
6"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
24.76 Hz
Equivalent Compliance (Vas)
175.5596 liters
Total Speaker Q Value (Qts)
0.5015
Electrical Q Value (Qes)
0.5749
Electrical Resistance of Voice Coil (Re)
4.0953 ohm
Mechanical Q Value (Qms)
3.9285
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

PCO.12

Weight:

12.00lbs

Internal SKU:

pco12

Internal Product ID:

79667

Product and How-to Videos


Customer Ratings & Reviews


Soundstream PCO.12 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
4.8
Features
4.8
Design
4.8
Usability
5

Customer Reviews

Sort by:

Loading...

Soundstream PCO.12

I love my Soundstream PCO.12!!!! I am very happy with this purchase and the price I got this sub for. I may be upgrading and adding a second one to my system. I purchased a Soundstream TX 2.350 and for a single 12 this rocks the Mazda.

By Steven on August 30, 2014

19 found this helpful


PCO.12

The sub is outstanding for the price. I went from Rockford Fosgate to Soundstream and the sound quality is better.

By BGK on February 18, 2015

13 found this helpful


Awsome Subwoofer

This is a AWSOME subwoofer. I ordered two of them to put in a dual enclosure. " Belva MDFD12" for the recommended sealed air space. and two " KICKER DX250.1" amps running each sub individually. let me tell you, these subs BUMP. Great sound, good highs and lows. If your looking for high quality sound for a good price this is it. just follow the subs recommended requirements and you wont be let down.
had for a month and there hitting strong

By James on June 1, 2015 Checkmark Icon Verified purchase

11 found this helpful


Excellent subs for the price

I bought these without hearing them in person. I figured for the price and with Soundstream's longevity, it was worth it. I hooked them up to my existing amp which runs 300 watts RMS to each 4 ohm sub. These replaced my older Infinity Perfect 12's and they are much cleaner and tighter and louder than those. I have been into car stereo aftermarket systems since I was a teenager and I am now mid-40's, so I have heard tons of subs from multiple manufacturers and I know what sounds right and why. These subs can easily shake my rearview mirror so badly I can't see out of it but they are also very clean sounding. One of my favorite songs to audition subs is "Jurassitol" by Filter because it has multiple bass lines and digital bass playing simultaneously and lesser subs can blur all of the bass together. These subs make everything stand out as individual instruments and sounds, so clarity is excellent. Especially given the fact that I am only tapping my existing subwoofer high output speaker level from my car's factory subs and running that through Soundstream's digital bass processor that takes the high input and outputs RCA's to the amp with either a 5 volt or 10 volt signal. If you want more bass but you have a very complicated factory system like mine with Nav and Bluetooth and backup camera, this is the way to go. These subs integrate well into the factory system as the existing factory "subwoofer" had horrible bass extension. Now my system slams cleanly and I still get to keep all of my factory stuff untouched. I also chose these subs because you don't have to feed them 1,000 watts just to get them to move. You don't need to buy expensive subs with huge magnets unless you are competing professionally. Two of these in a 1 cubic foot per speaker cabinet and a good amp around 250-300 clean RMS watts is all you need to really hit hard.

By Jimmy on December 7, 2015 Checkmark Icon Verified purchase

5 found this helpful
