See all parts that fit your 2020 Macan

JL Audio 10W0v3-4 - Buy One Get One 50% Off

Pair of 300W 10" W0v3 Series Single 4 Ohm Subwoofers

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

• 2 Subs
• 1200W Peak
• 600W RMS
• Mineral-Filled, Polypropylene Cone Woofer
• DMA Optimized Motor System
• Elevated Frame Cooling
• Lead Wire Woven Into Spider

Learn more about the 10w0v34_2

We apologize

This item has been discontinued


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

PH654 main

Cerwin-Vega PH654

600W Peak (300W RMS) 6.5" PRO Series Full Range Coaxial 4-ohm Speakers

2
-16.67%

$189.99

List price $227.99

Product Highlights


• 2 Subs
• 1200W Peak
• 600W RMS
• Mineral-Filled, Polypropylene Cone Woofer
• DMA Optimized Motor System
• Elevated Frame Cooling
• Lead Wire Woven Into Spider

Description


JL Audio brand icon

Authorized dealer

Product Features

  • 1 Pair of 10" Single 4 Ohm W0v3 Series Subwoofers
  • Power Ratings:
    • RMS: 600 watts Per Pair / 300 watts Each
  • Recommended Power Range: 300-600 watts
  • Impedance Per Pair: 2 Ohm or 8 Ohm
  • Mineral-filled, polypropylene cone woofer for excellent durability
  • Large roll surround for generous amounts of excursion
  • Elevated frame cooling brings air directly to the voice coil
  • Designed for compact sealed enclosures or medium-sized ported enclosures
  • Large excursion for louder bass and less distortion
  • DMA Optimized motor system reduces distortion and tight, clean bass
  • Lead wire woven into spider for added strength
  • Metallic silver frame finish
  • 2" Voice coil size
  • 5-1/4" Magnet diameter
  • Sensitivity: 84.07 dB
  • Black Steel-Mesh Grille Insert Available: JL Audio SGRU-10
  • 1-year Manufacturer's Warranty

JL Model Comparison
From entry level woofers to competition grade, JL has them all. Let us find which one works for you.

Model RMS Power Cone Material Surround Material Sensitivity (dB) Frequency Response Xmax (mm Terminals Made In America
W7 Series 500-1500 Watts Polypropylene Foam Overroll 82.7 - 86.3 15-250 Hz 19-32 Push Terminals
W6 Series 600 Watts Polypropylene Rubber 82.7 - 85.4 20-200 Hz 19 Push Terminals
W3 Series 150-600 Watts Polypropylene Rubber 80.5-87.90 20-250 Hz 8.89-15.5 Push Terminals
W1 Series 150-300 Watts Polypropylene Rubber 83.9-86.1 22-200 8-11 Push Terminals
W0 Series 300-500 Watts Polypropylene Foam 84-88.20 20-250 Hz 11.4-12.7 Push Terminals
WX Series 200 Watts Polypropylene Foam 86-87.17 22-250 Hz 10 Spade Terminals

Product history:

JL Audio 10W0v3-4_2 thumbnail
(newest, current model)
JL Audio 10W0v2-4 thumbnail
(previous model, replaced by JL Audio 10W0v3-4 - Buy One Get One 50% Off)

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 10W0v3-4 - Buy One Get One 50% Off Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 10W0v3-4 - Buy One Get One 50% Off Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 10W0v3-4 - Buy One Get One 50% Off Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 10W0v3-4 - Buy One Get One 50% Off Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

SQW104 small

NVX SQW104

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.23"
• Sensitivity: 83 dB

$249.99

List price $299.99

10TW3-D4 small

JL Audio 10TW3-D4

• RMS Power: 400 watts
• Polymer/Mica Composite Cone
• Rubber Surround
• Impedance: Dual 4 ohm
• Mount depth: 3.25"
• Sensitivity: 82.10 dB

(29)

$519.99

List price $519.99

10W0v3-4 small

JL Audio 10W0v3-4

• RMS Power: 300 watts
• Impedance: Single 4 ohm
• Mount depth: 4.90"
• Sensitivity: 84.07 dB

(68)

$139.99

List price $139.99

Specifications & Details


Subwoofer Specifications
Series
W0 v3 Series
Subwoofer Size
10"
Peak Power Handling
600 watts
RMS Power Handling
300 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2"
Frequency Response
25 - 250 Hz
Sensitivity
84.07 dB
Xmax (millimeters)
11.4 mm
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Large Roll
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.65 cubic feet
Maximum Sealed Box Volume
0.65 cubic feet
Minimum Ported Box Volume
0.75 cubic feet
Maximum Ported Box Volume
0.75 cubic feet
Top-Mount Depth (Mounting Depth)
4-7/8"
Cutout Diameter
9-1/16"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
32.09 Hz
Equivalent Compliance (Vas)
31.01 liters
Total Speaker Q Value (Qts)
0.604
Electrical Q Value (Qes)
0.64
Electrical Resistance of Voice Coil (Re)
4.280 ohm
Mechanical Q Value (Qms)
10.752
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

10W0v3-4_2

Weight:

19.24lbs

Internal SKU:

10w0v34_2

Internal Product ID:

98318

Product and How-to Videos


Customer Ratings & Reviews


JL Audio 10W0v3-4 - Buy One Get One 50% Off thumbnail image

5 star
88%
4 star
10%
3 star
1%
2 star
0%
1 star
0%



Durability
4.9
Value
4.9
Features
4.9
Design
4.9
Usability
5

Customer Photos & Videos


Customer Reviews

Sort by:

Loading...

Great little sub

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I had one of these in a small sealed wedge box in a grand cherokee powered by a JL 100/2 amp bridged of course and it was great. Break in was short maybe 10 hours of play time and a bit of tweaking. Some settings every one thought i had a 12.

By Noisebringer on January 8, 2012

93 found this helpful


great sub!

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

Great sub for the price!! Sounds amazing and because of the room I have under the back seat the sub is in a box that is half the size that JL calls for. I couldnt imagine how great it would sound in the right box!

By trent on April 30, 2014

84 found this helpful


amazing sq!

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I bought it for a sq build for decent kick drum thump, and it exceeded my expectations greatly. i was downsizing my build from two PSI 15's on 2kwrms, to this on ~320wrms am i'm not dissapointed! i built a box to jl spec but tuned to 28hz for a flatter, sq response curve. this dude dominates low lows and the xmax is ridiculous and no distortion! it is a very musical sub. the only downside is that i wish it had alittle tighter bass, but it could be the box, but my 6x9's in the doors handle that decently. buy this sub!

By Will on December 9, 2013

79 found this helpful


Nice sub

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I just bought this from a shop around me. It is in a sealed box behind my seat in a regular cab s10. The bass boost on my amp is on zero and this speaker is still loud. I will go back and buy another and hopefully port the boxes and blow my doors off. I highly recommend

By Andrew on October 18, 2012

78 found this helpful


Awsome!

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I'm using this JL Audio 10W0v3 -4 with a FLI 450S-2 in a Single 10" Sealed MDF Enclosure (10SQTC) and it rocks pretty hard! I have this rear firing in my 1996 jeep cherokee and it definatly compliments my JL 5.25's quite nicely. I have reviews written for the other two items written as well. Check them out!

By jacob on January 10, 2012

74 found this helpful


awesome sub

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

Can take a lot of power and has extreme excursion. Rather small depth wise for the amount of quality sound it produces. 1 is more than enough in my standard cab silverado with a kenwood 5 chanel amp

By stick rick on September 4, 2013

73 found this helpful


great seller, great product

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

Fast shipping, great product, great seller! Would highly recommend this seller

By AJ on August 13, 2012

72 found this helpful


great sub

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I had the older model subs in my single cab truck and if these are any thing like those look out they are bad and hit hard.

By freddie on January 1, 2012

70 found this helpful


JL Audio 10w3v4

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

All I have to say is badass. Enough said. Anything else is just bragging ;)

By Butch on August 6, 2013

72 found this helpful


JL Sub 10"

The following review is for 10W0v3-4, which is a part of the bundle you are viewing.

I bought this sub for my truck in January. Now 6 months later still hitting hard. If you want some bass in your vehicle but not overboard this is the sub to go. Hits good and catches most beats with a crisp sound. Overall well worth the money spent, would definitely buy another!!!!

By Curtis on July 30, 2013

66 found this helpful
