Name: Rockford Fosgate Punch P400-2 Open Box
Brand: Rockford Fosgate
SKU: LS-07-p400-2-OB
Price: 180.00 USD
Availability: Discontinued

by Rockford Fosgate

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

Rockford Fosgate Punch P400-2 Open Box Image 1 — Rockford Fosgate Punch P400-2 Open Box

Rockford Fosgate Punch P400-2 Open Box Image 2 — Rockford Fosgate Punch P400-2 Open Box

Rockford Fosgate Punch P400-2 Open Box Image 3 — Rockford Fosgate Punch P400-2 Open Box

Rockford Fosgate Punch P400-2 Open Box Image 4 — Rockford Fosgate Punch P400-2 Open Box

Rockford Fosgate Punch P400-2 Open Box Image 5 — Rockford Fosgate Punch P400-2 Open Box

Rockford Fosgate Punch P400-2 Open Box-video

Product videos

Product highlights

Punch Series 2-Channel Class AB Car Amplifier • 100W x 2 chan. @ 4 ohm • 200W x 2 chan. @ 2 ohm • MOSFET power supply • RCA Pass-thru outputs

Learn more about the LS-07-p400-2-OB

Product Highlights

Punch Series 2-Channel Class AB Car Amplifier • 100W x 2 chan. @ 4 ohm • 200W x 2 chan. @ 2 ohm • MOSFET power supply • RCA Pass-thru outputs

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Punch Series 2-Channel Class AB Car Amplifier
RMS Power Rating:

4 ohm: 100 watts x 2 chan.
2 ohm: 200 watts x 2 chan.
Bridged, 4 ohm: 400 watts x 1 chan.

MOSFET power supply
Remote bass level input (remote level control sold separately)
LED power, thermal, and protect indicators
Tuned Bass EQ (0-18 dB bass boost at 45 Hz or 0-12 dB bass boost at 12 kHz depending on crossover selection)
On-board differential inputs eliminates noise picked up by the signal cable
2/1 channel operation
Integrated Trans•ana technology simplifies the signal path of the amplifier allowing the signal to travel through the amplifier at a lower voltage. The result is greater reliability and exceptional sound quality.
RCA Pass-thru outputs
Featured custom designed TO-247 MOSFETs have 60% more metal tab area providing more power handling capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in most competitor's amps.
Built in NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.
Cast aluminum heatsink evenly distributes excess heat across entire amplifier heatsink
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Variable high-pass filter (50-500 Hz, 12 dB/octave)
Variable low-pass filter (50-500 Hz, 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 20-20000 Hz
Dimensions: 10.25"L x 7.625"W x 2.25"H
4-gauge power and ground leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
1-year SonicElectronix.com warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 2 channel

RMS Power @ 2 ohms

200 watts x 2 channel

Bridged RMS Power

400 watts x 1 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

2-Channel

Total RMS Power Output

400 watts

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

50 - 500 Hz

Low-Pass Crossover Frequency

50 - 500 Hz

Signal-to-Noise Ratio

85 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Rockford Fosgate PEQ

Fuse Rating

80A x 1
