RE Audio SE2200

600W Max SE Series Full Range Class A/B 2-Channel Amplifier

RE Audio
Shop all RE Audio
Product videos
highlight-star-icon

• 150 Watts RMS x 2 @ 4 ohm
• 280 Watts RMS x 2 @ 2 ohm
• 500 Watts RMS x 1 Bridged @ 4 ohm
• Total Peak Power: 600 Watts
• Variable low and high pass filter: 50 - 150Hz, 12 dB/octave
• Variable Bass Boost: 0 to +18 dB bass boost
• Dimensions: 8.78"W x 12.2"L x 2.25"H

Learn more about the se2200

We apologize

This item has been discontinued


Loading...
VSP68 main

NVX VSP68

600W Peak (200W RMS) 6x8" V-Series 2 Way Coaxial Car Speakers

46
-16.67%

$89.99

List price $107.99

MPR2110 main

Jensen MPR2110

Single DIN Digital Media Receiver with Bluetooth

13
P152 main

Rockford Fosgate Punch P1 P152

160W Peak (80W RMS) 5.25" Punch Series 2 Way Coaxial 4-ohm Speakers

27

Product Highlights


• 150 Watts RMS x 2 @ 4 ohm
• 280 Watts RMS x 2 @ 2 ohm
• 500 Watts RMS x 1 Bridged @ 4 ohm
• Total Peak Power: 600 Watts
• Variable low and high pass filter: 50 - 150Hz, 12 dB/octave
• Variable Bass Boost: 0 to +18 dB bass boost
• Dimensions: 8.78"W x 12.2"L x 2.25"H

Description


RE Audio brand icon

Authorized dealer

General Features:

  • RE Audio SE Series SE2200
  • Class-A/B Full Range 2-Ohm Stable 2-channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 150 watts x 2 chan.
    • 2 ohm: 280 watts x 2 chan.
    • Bridged @ 4 ohm: 500 watts x 1 chan.
  • Total power output: 600 watts
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • 2 or Mono channel operation
  • RCA outputs to daisy chain multiple amps
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Input sensitivity: 0.25V - 8V
  • Frequency Response: 20 - 20kHz
  • Total Harmonic Distortion (THD): 0.05%
  • Signal to Noise Ration: 90 dB
  • Variable low-pass filter: 50 - 150Hz, 12 dB/octave
  • Variable high-pass filter: 50 - 150Hz, 12 dB/octave
  • Variable Bass Boost: 0 to +18 dB bass boost
  • Phase Shift: 0° - 180°
  • Fuse Rating: 30 A x 1
  • 4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
  • Dimensions: 8.78"W x 12.20"L x 2.25"H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
Check out the SE2200 Owner's Manual

Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
150 watts x 2 channel
RMS Power @ 2 ohms
280 watts x 2 channel
Bridged RMS Power
500 watts x 1 channel
Power Specifications - Full Range Channels
Peak Power @ 4 ohms
300 watts x 2 channel
Peak Power @ 2 ohms
560 watts x 2 channel
Bridged Peak/Max Power
600 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
2-Channel
Total Peak Power Output
600 watts
Total RMS Power Output
500 watts
THD at Rated RMS Power
0.05%
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
50 - 150 Hz
Low-Pass Crossover Frequency
50 - 150 Hz
Signal-to-Noise Ratio
90 dB
Bass Boost
0 - 18 dB
Fuse Rating
30A x 1
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

SE2200

Weight:

10.00lbs

Internal SKU:

se2200

Internal Product ID:

107313
