Power Acoustik BLADE4-1200D

1200W Peak (600W RMS) Blade Series Class-D 4-Channel 2-Ohm Stable Amplifier

Product videos
highlight-star-icon

• 100 Watts RMS x 4 @ 4 ohm
• 150 Watts RMS x 4 @ 2 ohm
• 300 Watts RMS x 2 @ 4 ohm
• Total Peak Power: 1200 Watts
• Variable high-pass filter: 40 - 400 Hz, 12 dB/octave
• Variable low-pass filter: 40 - 400 Hz, 12 dB/octave
• Hybrid Aluminum Alloy Diecast Heatsink for Optimum Dissipation
• Dimensions: 5"W x 8"L x 2"H

Learn more about the blade41200d

We apologize

This item has been discontinued


Loading...
Limited time!
Stage3 527 main

JBL Stage3 527 (STAGE3527AM)

400W Peak (80W RMS) 5.25” Stage3 Series 2 Way Coaxial 3-ohm Speakers

2
-36.38%

$69.95

List price $109.95

Product Highlights


• 100 Watts RMS x 4 @ 4 ohm
• 150 Watts RMS x 4 @ 2 ohm
• 300 Watts RMS x 2 @ 4 ohm
• Total Peak Power: 1200 Watts
• Variable high-pass filter: 40 - 400 Hz, 12 dB/octave
• Variable low-pass filter: 40 - 400 Hz, 12 dB/octave
• Hybrid Aluminum Alloy Diecast Heatsink for Optimum Dissipation
• Dimensions: 5"W x 8"L x 2"H

Description


Power Acoustik brand icon

Authorized dealer



General Features:

  • Power Acoustik Blade Series BLADE4-1200D
  • Class-D FullRange 2-Ohm Stable 4-Channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 100 watts x 4 chan.
    • 2 ohm: 150 watts x 4 chan.
    • Bridged, 4 ohm: 300 watts x 2 chan.
  • Total power output: 1200 watts
  • Pulse Width Modulated MOSFET power supply
  • Wired remote bass level control included
  • LED power (green) and protect (red) indicators
  • Soft start turn-on
  • 4/3/2 channel operation
  • Speaker-level (high-level) inputs
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Dual speaker terminals simplify the hookup of multiple speakers
  • Hybrid Aluminum Alloy Diecast Heatsink for Optimum Dissipation
  • Variable high-pass filter: 40 - 400 Hz, 12 dB/octave
  • Variable low-pass filter: 40 - 400 Hz, 12 dB/octave
  • Fuse Rating: 40A x 1
  • 4 - 8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
  • Dimensions: 5"W x 8"L x 2"H
  • Authorized Internet Dealer
  • 1-year Sonic Electronix Warranty
