Pioneer TS-W1008D2 (tsw1008d2) 10" Dual 2 ohm Premier Champion

Pioneer Premier TS-W1008D2

10" Dual 2 ohm Premier Champion Series Subwoofer

10" Premier Champion Series Subwoofer • 1200 Watts Max • 350 Watts RMS • Dual 2 ohm • Reinforced IMPP Cone • Fiber Woven Radial Surround • Copper Voice Coil • Aramid Fiber Spider

We apologize

This item has been discontinued

DESCRIPTION
Pioneer

Authorized dealer

  • 10" Dual 2 ohm Premier Champion Series Subwoofer
  • Power Handling:
    • Peak: 1200 watts
    • RMS: 350 watts
  • Impedance: Dual 2 ohm
  • Interlaced basalt/carbon fiber reinforced IMPP cone
  • Cone reinforcement arcs cone design
  • Wide roll, three-layer fiber woven radial surround
  • Stamped basket with magnet cover
  • Copper voice coil with phenol resin coated glass cloth voice coil bobbin
  • Aramid fiber spider
  • 4-Layer, Long Voice Coil
  • Frequency response: 20-180 Hz
  • Sensitivity: 90 dB
  • 2-year SonicElectronix.com warranty

Product history:

Pioneer TS-W1008D2 thumbnail
(newest, current model)
Pioneer TS-W1007D2 thumbnail
(previous model, replaced by Pioneer Premier TS-W1008D2)
FEATURES & SPECS
Subwoofer Specifications
Subwoofer Series
Subwoofer Size
10"
Peak Power Handling
1200 watts
RMS Power Handling
350 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohms
Voice Coil Diameter
Frequency Response
20 - 180 Hz
Sensitivity
90 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Injection Molded Polypropylene with Carbon, Glass Fiber
Woofer Surround
Fiber Woven Radial
Magnet Structure
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Minimum Sealed Box Volume
0.65 cubic feet
Optimum Sealed Box Volume
Maximum Sealed Box Volume
1.25 cubic feet
Optimum Ported Box Volume
Top-Mount Depth
5-5/8"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
Equivalent Compliance (Vas)
Total Speaker Q Value (Qts)
Electrical Q Value (Qes)
Electrical Resistance of Voice Coil (Re)
Mechanical Q Value (Qms)
Efficiency Bandwidth Product (EBP)
What is in the box?
WITB: Subwoofers
Paperwork
Other Accessory #1
Other Accessory #2
Other Accessory #3
Other Accessory #4
Other Accessory #5
Authorized Dealer
Authorized Dealer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix
VIDEOS AND HOW - TO
REVIEWS
Pioneer Premier TS-W1008D2

Pioneer Premier TS-W1008D2

4.7

(15)

Write a review

Overall rating distribution

5 star
73%
4 star
27%
3 star
0%
2 star
0%
1 star
0%

By feature average rating

Durability
4.7
Value
4.8
Features
4.6
Design
4.6
Usability
4.8

Tyler

February 5, 2010

preety good

this sub hits pretty good i think pioneer over rated the rms because i am rms 300 and it seems like it distorts when its turned up allot but dont get me wrong it it pretty dang good for its money

14

found this helpful.

theo

December 9, 2010

Great Speakers

These speakers are the only one's that I use in my partybus. Would use anything else for the money!!!!

10

found this helpful.

aaron

January 24, 2011

Rediculous

Dude these subs are ridiculous I just got them two days ago I hooked them up to my alpine 760 watt amp and these things r shaking my windows. You cant beat these speakers for the price

9

found this helpful.

Richard

December 29, 2010

Very Good Sub

I have two of these subs in a ported enclosure in my extended cab nissan and the enclosure is tuned to about 37hz. They perform great and I get compliments on how they sound all the time. Pioneer builds a great product for the price and you won't be dissatisfied with this sub if your looking for a good entry level sub.

9

found this helpful.

Timothy

December 8, 2010

very happy

This woofer is very good, so good in fact my amp blew first.

9

found this helpful.

A Dude

June 13, 2010

Best 10's ive ever had

after going through some kenwoods with no luck i found these on this website and these are the only subs i get now (mainly because i only have 10 inch boxes haha) but nonetheless these are great subs. Given adequate power and such (i used 280 watts) they didn't distort as far as i can tell and are very loud (for what they are). My car windows and mirrors rattle (with ease) with 2 of these in a sealed box. Also having dual voice coils allows lots of wiring options. There's much louder subwoofers out there but for low powered 10 inch's they're well worth the 65$. Good stuff

9

found this helpful.

Jake

January 27, 2011

sweet sub

I purchased this sub about 6 months ago. I have it in a .8 cubic foot seal box. Powered by a Kicker kx 250.2 bridged to 4 ohms at 310 watts rms. The bass hits hard and tight. Sound great up to about 3/4 volume. It might sound better at higher volume in a ported box. A great value

8

found this helpful.

killa priest

January 12, 2011

great sub

I have one of these in a ported box tuned to 44 hz with a Sony xplod amp wired to 4 ohms pushin 330 rms. Took about a week and a half to break in and is now hitting like a college brawl.

Somebody asked today if I had 12's in my trunk and was surprised that it was one 10 inch sub. I'm planning on buying another before the price goes up again.

9

found this helpful.

WARREN

December 20, 2010

BEST PRICE FOR THE UNIT

I have recomended this product to my freinds . It is top for the money . Sound is great

8

found this helpful.

Ryan

November 4, 2010

Awesome subs.

I have two of these subwoofers in a dual vented box wired in series, then in parallel, both getting 200w rms ea from a mono Pioneer GM-D7500M amplifier. It's been about a month now and they're fully broke in. They sound amazing, and bump freakin hard in my 89 Corolla trunk. Best subwoofer for the price range, you wont be disappointed. I have them tuned around 80hz. Great product, and definitely wont find it cheaper anywhere else!

8

found this helpful.

ALEX

February 21, 2011

GREAT BASS POUNDING BEASTS

These things are beasts , i have 2 running on a kicker zx750.1 , everyone knows where i'm at cuzz i'm always bangin' , ........ Keep bangin'

7

found this helpful.

dave

February 19, 2011

very nice item

I would buy another one just like it if I had to. Loved it!

7

found this helpful.

Sam

August 17, 2010

Great

I am very pleased with this sub. Subs way better then my friends MTX woofers. Sub is very well constructed and it hits very low notes. Exactly what I was looking for cheap and small. I can still use my trunk.

7

found this helpful.

JW

October 17, 2010

HELP

Just wondering if you would need an amp to power this or if you could just hook it up to the stereo.

8

found this helpful.

ken j.

September 24, 2010

awesome sound

This speaker sounds great for it to be a 10 inch. Along with the price, it is an unbeatable deal. If you are looking to upgrade but keep your sound personal (within your vehicle) this is it.

5

found this helpful.
ACCESSORIES
WIRING GUIDE
Wiring Guide to Wire 1 Pioneer Premier TS-W1008D2 Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Pioneer Premier TS-W1008D2 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Pioneer Premier TS-W1008D2 Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 Pioneer Premier TS-W1008D2 Subwoofers

2 Channel Amp

4 Channel Amp
