Pioneer GM-ME400X4

1200W Peak (600W RMS) ME-Series Class-D 4-Channel Marine Amplifier

Pioneer
Shop all Pioneer
highlight-star-icon

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 1 ohm Stable 4-Channel Amplifier

Learn more about the gmme400x4

We apologize

This item has been discontinued


Loading...
MDA1B main

Scosche MDA1B Antenna Adapter

Connect your factory antenna to a new aftermarket radio for select 1958-2023 vehicles from GMC, Chevrolet, Pontiac

366
-33.07%

$5.99

List price $8.95

99-3001 main

Metra 99-3001 Dash Kit

Install a new Single-DIN car stereo in select 1988-1999 vehicles from Chevrolet, GMC trucks (Matte Black)

-42.32%

$14.99

List price $25.99

70-1855 main

Metra 70-1855 Wiring Harness

Install a new car stereo and retain factory amplifier in select 1988-1994 vehicles from Chevrolet, GMC, Buick

8
-43.25%

$20.99

List price $36.99

FRING4 main

NVX FRING4

Universal 4" Self-Adhesive Foam Speaker Baffle Ring Kit (Pack of 2)

4
-36.91%

$11.98

List price $18.99

560BRGB main

Boss Elite 560BRGB

Single DIN CD Receiver with Bluetooth (Black)

3
C1-400x main

JL Audio C1-400x

70W RMS 4" C1 Series 2 Way Coaxial 4-ohm Car Speakers

8

Description


Pioneer brand icon

Authorized dealer

Product Details:

  • ME Series Class D 1 ohm Stable 4-Channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 75 watts x 4 channel
    • 2 ohm: 100 watts x 4 channel
    • Bridged: 200 watts x 2 channel @ 4 ohm
  • Total power output: 600 watts
  • LED Power/Protect Light
  • Speaker-level (high-level) inputs
  • 1 pair of pre-amp outputs
  • Signal sensing remote turn-on
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Rubber covers protect side panel controls
  • Conformal coating ingress protection
  • Aluminum Top Plate
  • CTA-2006 compliant
  • Input sensitivity:
    • Low level: 200mV - 6.5 volts
    • High level: 800mV - 16 volts
  • Frequency Response: 10 - 35000 Hz
  • Total Harmonic Distortion (THD): 1%
  • Signal to Noise Ratio: 75 dB
  • Variable high-pass filter: 40 - 500 Hz
  • Variable low-pass filter: 40 - 500 Hz
  • Fuse Rating: 60A
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 10-3/4" L x 8-7/16" W x 2-7/16" H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • MFR #: GM-ME400X4
