Name: RE Audio XT-800.2V3 Factory Refurbished
Brand: RE Audio
SKU: LS-xt8002v3-RB
Price: 114.99 USD
Availability: Discontinued

by RE Audio

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

RE Audio XT-800.2V3 Factory Refurbished Image 1 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished Image 2 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished Image 3 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished Image 4 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished Image 5 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished Image 6 — RE Audio XT-800.2V3 Factory Refurbished

RE Audio XT-800.2V3 Factory Refurbished-video

Product videos

Product highlights

XT V3 Series 2-Channel Digital Car Amplifier • Class DE • 250W x 2 Chan. @ 2 Ohm • 125W x 2 Chan @ 4 Ohm • 500W Bridged • Elevated Efficiency Platform • High-Pass Filter • Low-Pass Filter • Aluminum Heatsink

Learn more about the LS-xt8002v3-RB

Product Highlights

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

RE Audio XT Amplifier Series

Working in a successful car audio system requires careful planning and quality components. Working in more affordable pricing for high quality product is easier now more than ever with RE Audio’s introduction of the XT Series of amplifiers. The entire line is crafted with precision from the ground up, beginning with the perfectly symmetrical circuit boards – RE Audio designs these with pride showcasing their cleanliness from the circuitry up.

An elevated efficiency platform makes these amplifiers drain less strain on your vehicles charging system to allow for more power output with less draw from your vehicles battery and alternator. Great power output in an affordable package with clean power output is what’s desired from every amplifier on the market, and the RE Audio XT Series of amplifiers provides this with their Multi-Channel and Monoblock lineups.

Offering specific models for 2-Channel, 4-Channel, and Monoblock applications RE Audio has provided a plethora of options to use their amplifiers in, be it an entry level system to a high end competition system. XT Series Amplifiers provide some of the best available value, and don’t cut back on their quality – an amplifier that truly defines quality meeting value.

XT V3 Series 2-Channel Class DE Car Amplifier
RMS Power Rating:
- 4 ohm: 125 watts x 2 chan.
- 2 ohm: 250 watts x 2 chan.
- Bridged, 4 ohm: 500 watts x 1 chan.
Dynamic (Max) power output: 1000 watts
High speed digital stereo amplifier
Elevated Efficiency Platform guarantees the abundance of power, without a heavy drain on the vehicles charging system
Remote bass level input (remote level control sold separately)
Pulse Width Modulated MOSFET power supply
LED power (green) and protect (red) indicators
Variable Bass Boost (0 to +12 dB bass boost at 45 Hz)
Screw terminal barrier strip speaker connector accepts 8-18 AWG speaker wire
Soft start turn-on technology
2/1 channel operation
1 RCA Pair of preamp RCA outputs to daisy chain multiple amps
3-Way System Protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heatsink for excellent heat dissipation
Convention cooling system
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Maximum Input Signal: 6V
Maximum sensitivity: 200 mV
Fully adjustable butterworth high and low pass crossover filters
Variable high-pass filter (40-1,000 Hz, 12 dB/octave)
Variable low-pass filter (40-250 Hz, 24 dB/octave)
Subsonic filter (15-40 Hz, 24 dB/octave)
Average Efficiency:
- 4 ohm: 70%
- 2 ohm: 65%
Damping factor: 300 @ 4 ohm
Output Regulation: 0.12dB @ 4 ohm
Signal-to-Noise Ratio: 110 dB
Frequency response: 5-50,000 Hz
Dimensions: 9-3/4"L x 10"W x 1-7/8"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Also Found As: RE Audio, US Amps, XT8002V3, XT-8002V3, XT800 2V3, XT-800.2V2
Authorized Internet Dealer
90 Day Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

125 watts x 2 channel

RMS Power @ 2 ohms

250 watts x 2 channel

RMS Power @ 1 ohm

Not Stable

Bridged RMS Power

500 watts x 1 channel

Amplifier Specifications

Amplifier Class

Number of Channels

2-Channel

Total Peak Power Output

1000 watts

Total RMS Power Output

500 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.02%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

40 - 1,000 Hz

Low-Pass Crossover Frequency

40 - 250 Hz

Subsonic Filter

15 - 40 Hz

Signal-to-Noise Ratio

110 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Fuse Rating

25A x 1

Warranty and Return Policy

Parts Warranty Duration

90 days

Labor Warranty Duration

90 days

Warranty Provider

Manufacturer
