Name: Massive Audio NX5 Open Box
Brand: Massive Audio
SKU: LS-nx5-OB
Price: 239.95 USD
Availability: Discontinued

by Massive Audio

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

Massive Audio NX5 Open Box Image 1 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 2 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 3 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 4 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 5 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 6 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 7 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 8 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 9 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 10 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 11 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 12 — Massive Audio NX5 Open Box

Massive Audio NX5 Open Box Image 13 — Massive Audio NX5 Open Box

Product videos

Product highlights

Massive Audio NX5 Nano Block Series 5-Channel Car Amplifier • MOSFET Power Supply • LED Power/Protect Indicators • Ultimate Mounting Flexibility • Mill Spec Double Sided PCB with SMD Parts • Raven Black Finish

Learn more about the LS-nx5-OB

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Massive Audio NX5 Nano Block Series 5-Channel Car Amplifier
RMS Power Rating (14.4V):
- 4 ohm: 120 watts x 4 chan. + 300 watts x 1 chan.
- 2 ohm: 220 watts x 4 chan. + 500 watts x 1 chan.
- Bridged, 4 ohm: 240 watts x 2 chan. + 300 watts x 1 chan.
MOSFET power supply with high grade switching devices
LED power/protect indicators
Designed to fit into restrictive or limited spaces while still delivering staggering amounts of power
Ultra efficient Nano Technology power supplies and endless possible installation scenarios
2-Channel operation
Extreme power in a small footprint
Ultimate mounting flexibility (stackable, line array, side mount)
Mill Spec double sided PCB with SMD parts
Built-In noise reduction circuitry
Heavy duty aluminum alloy heatsink anodized in a Raven Black finish for extreme heat dissipation
3-Way protection circuitry (short circuit, overheating and Low Voltage)
Chrome-plated RCA level inputs
Chrome-plated screw terminals
Adjustable high-pass filter (40-200 Hz, 24 dB/octave)
Adjustable low-pass filter (20-200 Hz, 24 dB/octave)
Frequency response: 20-25,000 Hz
THD (Total Harmonic Distortion): <0.05%
Signal-to-Noise Ratio: >89 dB
Max Voltage: 15V
Max RCA Voltage: 5V
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
CEA-2006 compliant amplifier
Also found as: Massive Audio SKUNX2
Weight: 15 lbs
Dimensions: 15"L x 5-1/2"W x 2-1/8"H
90-Day Sonic Electronix warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

120 watts x 4 channel

RMS Power @ 2 ohms

240 watts x 4 channel

Bridged RMS Power

480 watts x 2 channel

Power Specifications - Subwoofer Channel

RMS Power @ 4 ohms

200 watts x 1 channel

RMS Power @ 2 ohms

400 watts x 1 channel

RMS Power @ 1 ohm

800 watts x 1 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

5-Channel

Total Peak Power Output

3520 watts

Total RMS Power Output

1160 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

<0.05%

Speaker Level Inputs

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

40 - 200 Hz

Low-Pass Crossover Frequency

20 - 200 Hz

Signal-to-Noise Ratio

>89 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Fuse Rating

Not specified by manufacturer

Warranty and Return Policy

Parts Warranty Duration

90 days

Labor Warranty Duration

90 days

Warranty Provider

Sonic Electronix
