U.S. acoustics USC2100

Product videos
highlight-star-icon

CEA-2006 Compliant • 310W RMS power amplifier • 165W x 2 @ 2 Ohm RMS • 100W x 2 @ 4 Ohm RMS • Gold plated RCA connectors • True Line Output • 0-18dB Bass Boost • Built in crossovers • High-current MOSFET output stages

Learn more about the usc2100

We apologize

This item has been discontinued


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

3
-16.67%

$349.99

List price $420.00

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Product Highlights


CEA-2006 Compliant • 310W RMS power amplifier • 165W x 2 @ 2 Ohm RMS • 100W x 2 @ 4 Ohm RMS • Gold plated RCA connectors • True Line Output • 0-18dB Bass Boost • Built in crossovers • High-current MOSFET output stages

Description


U.S. acoustics brand icon

Authorized dealer

  • Authorized Internet Dealer
  • CEA-2006 Compliant
  • 310 Watt RMS power amplifier
  • RMS Power Output: 165 watts x 2 chan. at 2 Ohm
  • High-current MOSFET device
  • MMT Regulated Power Supplies
  • 35 nanosecond switching diode
  • High capacity power transformer
  • Multiple bypass capacitors on incoming 12V supply
  • Time delay turn-on with opto-coupled muting circuits
  • Power supplies use pulse-width modulation
  • Thermal and reverse polarity protection
  • High speed, audio-grade components in all low stages
  • Active constant current bias tracking circuit
  • Gold-plated RCA inputs and connectors
  • Wide range of sensitivity accepts signal from any headunit
  • High-level speaker inputs
  • 24dB/Octave low pass crossover
  • True line output
  • AutoBridge feature
  • Short circuit protecion
  • Dimensions: 11" L x 9.5" W x 2.5" H
  • 1-year Manufacturer's warranty

Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 2 channel
RMS Power @ 2 ohms
165 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
310 watts x 1 channel
Amplifier Specifications
Number of Channels
2-Channel
Total RMS Power Output
330 watts
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.01%
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Signal-to-Noise Ratio
103 dB
Bass Boost
0 - 18 dB
Fuse Rating
30A x 2

Item Details


Manufacturer:

Model Number:

USC2100

Weight:

13.00lbs

Internal SKU:

usc2100

Internal Product ID:

2781

Product and How-to Videos


Customer Ratings & Reviews


U.S. acoustics USC2100 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
4
Design
5
Usability
4

Customer Reviews

Sort by:

Loading...

USC2100 best bang for your buck

i installed my USC2100 yesterday afternoon, its running two JL 12w0-8's wired paralell at 4 ohms. the usc really pounds hard and after a half hour of thorough bumping i was impressed by both the power of the little amp and the fact that it was still cool to the touch . i doubt you could beat the value of the us accoustics usc line if you are on a budget but want a hard hitting product.

By Sean on December 10, 2004
