Product highlights

X-Program 2-Channel Class AB Amplifier • 140W • Dual Speaker Terminals • Preamp RCA outputs • 3-Way System Protection Circuitry • Speaker-Level Inputs • Variable Bass Boost • Variable Low-Pass Filter • Phase Shift

Learn more about the xa20

Product Highlights

Description

Authorized dealer

X-Program by DLS: Born to Play

The DLS X-Program was designed for those that love their music and love to listen at high levels. This specialized line from DLS has everything you need for a high-end, audiophile sound system. With precise engineering, these items still offer complete control of your audio and help you preserve the sound quality. The X-Program from DLS is a Sonic Electronix exclusive and is the perfect blend of performance and price. Just like the rest of the DLS products, the X-Program is designed and engineered by DLS in Sweden.

Born with Extreme Technology

X-Program amplifiers use class AB technology that is either all on or all off, so these amplifiers have low heat build-up in idle positions and are nearly 90% efficient. These full range analogue class AB amplifiers produce incredible power from a compact package so you can fit them almost anywhere, even under your front seat! All X-Program amplifiers are 4-ohm and 2-ohm stable so you can maximize you’re wiring options for speakers or subwoofers. Low-pass and high-pass filters allow you to tune your system just right by feeding your speakers only the frequencies they can handle, which reduces distortion. Phase shift of 180 degrees allows you to keep your subwoofer in phase with your speakers for the best tonal accuracy. Wrapping everything up, the silver finned heat sink is elegant and efficient removing any harmful heat generated from intense musical sessions. X-Program amplifiers were born to play rough, don’t let their compact size fool you.

X-Program 2-Channel Class AB Amplifier
RMS Power Rating:
- 4 ohm: 50 watts x 2 chan.
- 2 ohm: 70 watts x 2 chan.
- Bridged 4 ohm: 140 watts x 1 chan.
Pulse Width Modulated MOSFET power supply
LED power (green) and protect (red) indicators
Variable Bass Boost (0 to +18 dB bass boost)
Soft Start Turn-on
2-Channel or Mono channel operation
Speaker-level inputs with signal sensing for automatic turn-on
3-Way System Protection circuitry (thermal, overload, and speaker short protection)
Dual speaker terminals simplify the hookup of multiple speakers
Heavy duty aluminum alloy heatsink sink for extreme heat dissipation
Gold-plated RCA level inputs
Gold-plated screw terminals
Input sensitivity:
- High level: 0.25mV-5V
Variable low-pass filter (50-250 Hz, 18 dB/octave)
Subsonic filter (25 Hz)
Phase Shift: 0-180°
Damping factor: >80
Frequency response: 20-30,000 Hz
Dimensions: 10-15/16"L x 10"W x 2-13/16"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Authorized Internet Dealer
1-year Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

50 watts x 2 channel

RMS Power @ 2 ohms

70 watts x 2 channel

RMS Power @ 1 ohm

Not Stable

Bridged RMS Power

140 watts x 1 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

2-Channel

Total Peak Power Output

Not Specified

Total RMS Power Output

140 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

Not Bridgeable

THD at Rated RMS Power

0.1%

Speaker Level Inputs

Yes

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)

High-Pass Crossover Frequency

Selectable Off / 70 / 90 Hz

Low-Pass Crossover Frequency

50 - 250 Hz

Subsonic Filter

25 Hz

Signal-to-Noise Ratio

>90 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Fuse Rating

25A x 1

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
