Name: Image Dynamics i4500 Open Box
Brand: Image Dynamics
SKU: LS-i4500-OB
Price: 229.99 USD
Availability: Discontinued

by Image Dynamics

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

Image Dynamics i4500 Open Box Image 1 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 2 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 3 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 4 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 5 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 6 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 7 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 8 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 9 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 10 — Image Dynamics i4500 Open Box

Image Dynamics i4500 Open Box Image 11 — Image Dynamics i4500 Open Box

Product videos

Product highlights

4-Channel Class AB i Series Car Amplifier • 460W RMS • Pulse Width Modulated MOSFET Power Supply • LED Status Indicator • Fully Adjustable Bass EQ • 3-Way System Protection • Low Level Line Inputs • Aluminum Finned Heatsink

Learn more about the LS-i4500-OB

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Affordable and Reliable I Series Amplifiers

Image Dyanimics' I series amplifiers are perfect for those looking to get a great performing amplifier that they can trust time and time again. The i4500 is a 4-channel amplifier that is rated at 75W RMS x 4 chan. @ 4 ohms, 115W RMS x 4 chan. @ 2ohms, and 230W RMS x 2 chan. @ 4ohms bridged. With that kind of power this amplifier will power up those brand new after market speakers or even some subwoofers at the bridged impedance. The amplifier features a heavy duty aluminum alloy heatsink for extreme heat dissipation and a 3-way protection system along with a soft star feature for ultimate protection. Low and high-pass filters and adjustable bass boost will give you complete control of fine tuning your audio system for the best sound possible. Low and high level inputs make this amplifier suitable for any vehicle and any application.

4-Channel Class AB i Series Car Amplifier
RMS Power Rating:
- 4 ohm: 75 watts x 4 chan.
- 2 ohm: 115 watts x 4 chan.
- Bridged, 4 ohm: 230 watts x 2 chan.
CEA Power Rating @ 14.4V:
- 2 ohm: 125 watts x 4 chan.

Pulse Width Modulated MOSFET power supply

LED status indicator

Fully adjustable bass EQ (0-18 dB @ 40 Hz)

Soft delay remote turn on/off circuit to eliminate pops and clicks

4/3/2 Channel operation

Low level line inputs and outputs

3-Way System Protection circuitry (thermal, DC, and speaker short protection)

Remote bass level sold seperately

Heavy duty aluminum finned heatsink for extreme heat dissipation

Silver-plated RCA level inputs

Silver-plated screw terminals

Silver-plated ground and power 8-gauge input terminals

Input sensitivity: 0.5V-4.0V

Variable High-Pass Filter (40-250 Hz)

Variable Low-Pass Filter (40-250 Hz)

Crossover Slope: 12 dB

Damping Factor: >150

THD (Total Harmonic Distortion): 0.5%

Frequency Response: 20-22,000 Hz

Signal-to-Noise Ratio: >94 dB

Fuse Rating: 2 x 30 amp

Dimensions: 14-15/16"L x 8"W x 2-1/4"H

4-gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.

1-year Manufacturer's Warranty

Note: Although the power and ground terminals only accept 8-gauge wiring, it is recommended to use 4-gauge wiring along with a Gauge Adapter to properly run this amplifier. For more information on proper wire lengths, please visit our Gauge Wire Article

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

75 watts x 4 channel

RMS Power @ 2 ohms

115 watts x 4 channel

RMS Power @ 1 ohm

Not Stable

Bridged RMS Power

230 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total RMS Power Output

460 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.5%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

40 - 250 Hz

Low-Pass Crossover Frequency

40 - 250 Hz

Signal-to-Noise Ratio

>94 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Fuse Rating

30A x 2

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
