Name: Crunch CR600.4RB
Brand: Crunch
SKU: LS-cr6004-RB
Price: 59.99 USD
Availability: Discontinued

by Crunch

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

Crunch CR600.4RB Image 1 — Crunch CR600.4RB

Crunch CR600.4RB Image 2 — Crunch CR600.4RB

Crunch CR600.4RB Image 3 — Crunch CR600.4RB

Crunch CR600.4RB Image 4 — Crunch CR600.4RB

Crunch CR600.4RB Image 5 — Crunch CR600.4RB

Product videos

Product highlights

Power One Series Car Amplifier • 4-Channel • Class AB • 300W x 2 Chan. Max • 150W x 2 Chan. @ 2 ohm • 75W x 4 Chan. @ 4 ohm • Tuned Bass EQ • Speaker-Level Inputs • Crossover Switch • LPF • HPF

Learn more about the LS-cr6004-RB

Product Highlights

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

Power One Series 2-Channel Class AB Car Amplifier
RMS Power Rating:
- 4 ohm: 37.5 watts x 4 chan.
- 2 ohm: 75 watts x 4 chan.
- Bridged, 4 ohm: 150 watts x 2 chan.
Dynamic Power Rating:
- 4 ohm: 75 watts x 4 chan.
- 2 ohm: 150 watts x 4 chan.
- Bridged, 4 ohm: 300 watts x 2 chan.
PWM MOSFET power supply
Power and protection LED indicators
Tuned Bass EQ (0-12 dB bass boost at 45 Hz)
4/2 channel operation
Speaker-level inputs with signal sensing for automatic turn-on
1 Pair of preamp RCA outputs
Full range line output RCA contacts
Unbalanced RCA inputs
Crossover switch for low-pass filter, high-pass filter, and full
Soft start technology for a slow, un-muted turn on
DC, speaker short, thermal, and overload protection
Comprehensive diagnostics system protect against speaker lead short circuit and amplifier DC faults
Adjustable input sensitivity from 6V - 0.2V
Aluminum alloy heatsink for excellent heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Variable high-pass filter (60-12,000 Hz, 12 dB/octave)
Variable low-pass filter (30-250 Hz, 12 dB/octave)
Frequency response: 10-45,000 Hz
Dimensions: 9"L x 9-7/8"W x 2"H
8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Authorized Internet Dealer
90-Day Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

37.5 watts x 4 channel

RMS Power @ 2 ohms

75 watts x 4 channel

Bridged RMS Power

150 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total Peak Power Output

600 watts

Total RMS Power Output

300 watts

Maximum Input Gauge Size

8 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Yes

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

60 - 12,000 Hz

Low-Pass Crossover Frequency

30 - 250 Hz

Signal-to-Noise Ratio

90 dB

Channel Separation

80 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Fuse Rating

25A x 1

Warranty and Return Policy

Parts Warranty Duration

90 days

Labor Warranty Duration

90 days

Warranty Provider

Manufacturer
