Name: Alpine PDX-V9 Open Box Missing (Good, Used)
Brand: Alpine
SKU: LS-pdxv9-OBM5
Price: 329.99 USD
Availability: Discontinued

by Alpine

About
Specs & Details
Reviews
Add-ons
Recently Viewed
Related Searches

Alpine PDX-V9 Open Box Missing (Good, Used) Image 1 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 2 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 3 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 4 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 5 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 6 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 7 — Alpine PDX-V9 Open Box Missing (Good, Used)

Alpine PDX-V9 Open Box Missing (Good, Used) Image 8 — Alpine PDX-V9 Open Box Missing (Good, Used)

Product highlights

• Full-Range RMS: 100W x 4 @ 4 ohm, 100W x 4 @ 2 ohm
• Subwoofer RMS: 500W x 1 @ 4 ohm, 500W x 1 @ 2 ohm
• CEA-2006 Compliant
• Super Efficient PDX Power Supply >90%
• Power Management Processor
• Dimensions: 10-5/8"W x 7-1/2"D x 2"H

Learn more about the LS-pdxv9-OBM5

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Good Condition (Used):
A Good Open Box used product shows wear from consistent use, but it remains in good condition and works perfectly. It may be marked, have identifying markings on it, or show other signs of previous use or installation. Original packaging or protective wrapping may be missing or not included in its entirety. Warranty details are included in the item description or comments.

General Features:

5-Channel PDX Series Car Amplifier
RMS Power Rating:

4 ohm: 100 watts x 4 chan. + 500 watts x 1 chan.
2 ohm: 100 watts x 4 chan. + 500 watts x 1 chan.
Bridged, 4 ohm: 200 watts x 2 chan.

PDX Technology for increased performance and durability
Sleek Aggressive Design w/ End Caps
Pulse Width Modulated MOSFET power supply
LED power (green) and protect (red) indicators
Variable Bass Boost (0 to +12 dB bass boost at 50 Hz)
Soft start turn-on
5/4/3 channel operation
Wired Bass Remote Ready

Alpine RUX KNOB Required and Sold separately

3-way protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heat-sink for extreme heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Input sensitivity:
Variable high-pass filter (30-600 Hz, 24 dB/octave)
Variable low-pass filter (30-600 Hz, 24 dB/octave)
Variable Subsonic filter (3-30 Hz)
Damping factor: >500
CEA-2006 compliant amplifier
Frequency response: 5-45,000 Hz
4 gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
Dimensions: 10-5/8"W x 7-1/2"D x 2"H
Authorized Internet Dealer
30-Day Return Policy

Product history:

	Alpine PDX-V9 Open Box Missing (Good, Used) (newest, current model)
	Alpine PDX-5 (previous model, replaced by Alpine PDX-V9 Open Box Missing (Good, Used))

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 4 channel

RMS Power @ 2 ohms

100 watts x 4 channel

Bridged RMS Power

200 watts x 2 channel

Power Specifications - Subwoofer Channel

RMS Power @ 4 ohms

500 watts x 1 channel

RMS Power @ 2 ohms

500 watts x 1 channel

Amplifier Specifications

Series

PDX Series

Amplifier Class

Number of Channels

5-Channel

Total Peak Power Output

1600 watts

Total RMS Power Output

800 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

.01%

Speaker Level Inputs

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

30 - 600 Hz

Low-Pass Crossover Frequency

30 - 600 Hz

Subsonic Filter

5 - 30 Hz

Signal-to-Noise Ratio

112 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Alpine RUX-KNOB: Remote Bass Level Control (will only control Channel 5)

Fuse Rating

40A x 2

Warranty and Return Policy

Parts Warranty Duration

Not warranted

Labor Warranty Duration

Not warranted

Warranty Provider

Manufacturer
