Name: Cerwin-Vega H41200.4 OPEN BOX COMPLETE
Brand: Cerwin-Vega
SKU: LS-h412004-OBCra223801
Price: 141.99 USD
Availability: Discontinued

by Cerwin-Vega

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 1 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 2 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 3 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 4 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 5 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 6 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 7 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 8 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE Image 9 — Cerwin-Vega H41200.4 OPEN BOX COMPLETE

Cerwin-Vega H41200.4 OPEN BOX COMPLETE-video

Product videos

Product highlights

Installed and has Box Damage
• RMS Power: 80W x 4 @ 4 ohm , 110 watts x 4 @ 2 ohm
• Total Peak Power: 1200W
• Variable Low-Pass Filter
• Pulse Width Modulated MOSFET Power Supply
• Heavy-Grade Aluminum Alloy Extruded Heatsink

Learn more about the LS-h412004-OBCra223801

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition: Open Box Complete

Installed and has Box Damage

General Features:

HED Series 4-Channel Class AB Car Amplifier
RMS Power Rating:

4 ohm: 80 watts x 4 chan.
2 ohm: 110 watts x 4 chan.
Bridged, 4 ohm: 220 watts x 2 chan.

Max Power Output: 1200W
Class AB Power Multi-Channel Topology Design
Heavy-Grade Aluminum Alloy Extruded Heatsink
Illuminated Ambient Lit Cerwin-Vega Logo
LED power (green) and protect (red) indicators
Power Supply Threshold: 10.0 VDC - 17.0 VDC
Total Harmonic Distortion: 0.1%
Signal to Noise Ratio (@1w): 85 dBa
Input Sensitivity: 0.2 mV - 6.0 V
Damping Factory: >70
Frequency Response: 10 - 45,000 Hz
Selectable Crossover: Full/HPF/LPF
Variable low-pass filter: 35 - 3500 Hz
Variable high-pass filter: 15 - 350 Hz
Variable Bass Boost (Rear Only): 0 - 9 dB
Fuse Rating: 30A x 2
8 gauge power and ground wiring is recommended for installation

Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier

Dimensions: 8.875"W x 16.85"L x 2.187H
Authorized Internet Dealer
1-year Manufacturer's Warranty

Check out the Cerwin-Vega H41200.4 Owner's Manual

Product history:

	Cerwin-Vega H41200.4 OPEN BOX COMPLETE (newest, current model)
	Cerwin-Vega HED31200.4 (previous model, replaced by Cerwin-Vega H41200.4 OPEN BOX COMPLETE)

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

80 watts x 4 channel

RMS Power @ 2 ohms

110 watts x 4 channel

Bridged RMS Power

220 watts x 2 channel

Amplifier Specifications

Series

HED Series

Amplifier Class

A/B

Number of Channels

4-Channel

Total Peak Power Output

1200 watts

Total RMS Power Output

440 watts

Maximum Input Gauge Size

8 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.1%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

15 - 350 Hz

Low-Pass Crossover Frequency

35 - 3500 Hz

Signal-to-Noise Ratio

85 dB

Bass Boost

0 - 9 dB

Remote bass/level controller

Fuse Rating

25A x 2

Strappable

Sonic Certified Amplifier

Not Tested

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
