See all parts that fit your 1998 Bravada

JL Audio 10WXv2-4 Buy One Get One 50% Off

Pair of 200W 10" WXv2 Series Single 4 ohm Subwoofers

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

• 2 Subs
• 800W Peak
• 400W RMS
• Polypropylene Woofer Cone Material
• Elevated Frame Cooling
• Integrated Foam Rear Gasket
• Resists Breakdown Under Extreme Conditions

Learn more about the 10wxv24_2

We apologize

This item has been discontinued


Loading...
DMH-341EX main

Pioneer DMH-341EX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth and Amazon Alexa

14
-31.43%

$240.00

List price $350.00

Product Highlights


• 2 Subs
• 800W Peak
• 400W RMS
• Polypropylene Woofer Cone Material
• Elevated Frame Cooling
• Integrated Foam Rear Gasket
• Resists Breakdown Under Extreme Conditions

Description


JL Audio brand icon

Authorized dealer

  • Product history:

    JL Audio 10WXv2-4_2 thumbnail
    (newest, current model)
    JL Audio 10WX-4 thumbnail
    (previous model, replaced by JL Audio 10WXv2-4 Buy One Get One 50% Off)

    Subwoofer Wiring Guide


    Wiring Guide to Wire 1 JL Audio 10WXv2-4 Buy One Get One 50% Off Subwoofer

    Mono Amp

    2 Channel Amp - Bridged

    Wiring Guide to Wire 2 JL Audio 10WXv2-4 Buy One Get One 50% Off Subwoofers

    Mono Amp

    2 Channel Amp

    4 Channel Amp - Bridged

    Wiring Guide to Wire 3 JL Audio 10WXv2-4 Buy One Get One 50% Off Subwoofers

    4 Channel Amp

    Wiring Guide to Wire 4 JL Audio 10WXv2-4 Buy One Get One 50% Off Subwoofers

    Mono Amp

    Mono Amp - Option 1

    2 Channel Amp

    2 Channel Amp - Bridged

    4 Channel Amp


    Loading...
    Limited time!
    46CSC654 main

    Kicker CSC65 (46CSC654)

    600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

    123
    -33.36%

    $79.96

    List price $119.99

    DMH-1800NEX main

    Pioneer DMH-1800NEX

    6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

    3
    -16.67%

    $349.99

    List price $420.00

    Club 322F main

    JBL Club 322F (SPKCB322FAM)

    150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

    1
    -27.29%

    $79.95

    List price $109.95

    Limited time!
    Club 622 main

    JBL Club 622

    360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

    5
    -28.58%

    $99.95

    List price $139.95

    DMH-W4660NEX main

    Pioneer DMH-W4660NEX

    6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

    2
    -20.00%

    $599.99

    List price $750.00

    43DSC6504 main

    Kicker DSC650 (43DSC6504)

    480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

    28
    -10.53%

    $84.99

    List price $94.99

    CV15BT main

    Cerwin-Vega CV15BT

    Single Din Digital Media Receiver with Bluetooth

    3
    UTE-73BT main

    Alpine UTE-73BT

    Single DIN Digital Media Receiver with Bluetooth

    44
    -16.69%

    $149.95

    List price $180.00

    Limited time!
    DMH-W3050NEX main

    Pioneer DMH-W3050NEX

    6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

    1
    -24.20%

    $469.99

    List price $620.00

    DB652 main

    Polk Audio DB652 (DB 652)

    600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

    12
    -9.16%

    $109.00

    List price $119.99


    Best selling similar products

    SQW104 small

    NVX SQW104

    • Peak Power: 1200 watts
    • RMS Power: 600 watts
    • Impedance: Dual 4 ohm
    • Polypropylene Cone
    • Rubber Surround
    • Mount depth: 3.23"
    • Sensitivity: 83 dB

    $249.99

    List price $299.99

    10TW3-D4 small

    JL Audio 10TW3-D4

    • RMS Power: 400 watts
    • Polymer/Mica Composite Cone
    • Rubber Surround
    • Impedance: Dual 4 ohm
    • Mount depth: 3.25"
    • Sensitivity: 82.10 dB

    (29)

    $519.99

    List price $519.99

    10W0v3-4 small

    JL Audio 10W0v3-4

    • RMS Power: 300 watts
    • Impedance: Single 4 ohm
    • Mount depth: 4.90"
    • Sensitivity: 84.07 dB

    (68)

    $139.99

    List price $139.99

    Specifications & Details


    Subwoofer Specifications
    Series
    WX Series
    Subwoofer Size
    10"
    Peak Power Handling
    400 watts
    RMS Power Handling
    200 watts
    Voice Coil(s)
    Single
    Impedance (Per Voice Coil)
    4 ohm
    Frequency Response
    25 - 250 Hz
    Sensitivity
    86.06 dB
    Xmax (millimeters)
    9.5 mm
    Subwoofer Design
    Round / Circle
    Main Cone Color
    Black
    Woofer Composition
    Polypropylene
    Woofer Surround
    Foam
    Magnet Structure
    Single Stacked
    Subwoofer Grille
    Optional (Accessory required and sold separately)
    Re-Cone Kit Available
    No
    Recommended Enclosure Specifications
    Recommended Enclosure Type
    Ported / Vented
    Sealed
    Minimum Sealed Box Volume
    0.63 cubic feet
    Maximum Sealed Box Volume
    0.63 cubic feet
    Minimum Ported Box Volume
    1.00 cubic feet
    Maximum Ported Box Volume
    1.00 cubic feet
    Top-Mount Depth (Mounting Depth)
    4-13/16"
    Cutout Diameter
    9-1/16"
    Shallow Mount Installation
    No
    T/S Parameters (Electromechanical)
    Free-Air Resonance (Fs)
    29.38 Hz
    Equivalent Compliance (Vas)
    47.01 liters
    Total Speaker Q Value (Qts)
    0.450
    Electrical Q Value (Qes)
    0.471
    Electrical Resistance of Voice Coil (Re)
    3.51 ohm
    Mechanical Q Value (Qms)
    10.02
    Warranty and Return Policy
    Parts Warranty Duration
    1 year
    Labor Warranty Duration
    1 year
    Warranty Provider
    Manufacturer

    Item Details


    Manufacturer:

    Model Number:

    10WXv2-4_2

    Weight:

    13.46lbs

    Internal SKU:

    10wxv24_2

    Internal Product ID:

    98321
