JL Audio 1000/1 (BLACK SPECIAL EDITION)

Black Heatsink Design Class D Monoblock Amplifier

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

1000 watts, MonoBlock Class D Amplifier

Learn more about the jl10001-black

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

CVP8 main

Cerwin-Vega CVP8 (Sold Individually)

350W Peak (170W RMS) 8" CVPRO Series Pro Full Range 4-ohm Speaker

-16.67%

$49.99

List price $59.99

Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

DMDX5 main

Diamond Audio DMDX5

240W Peak (80W RMS) 5" DMD Series 2-Way Cocentric Coaxial 4-ohm Speakers

DMDX8 main

Diamond Audio DMDX8

390W Peak (130W RMS) 8" DMDX Series 2-Way Cocentric Coaxial Car Speakers

S2-S30 main

Alpine S2-S30

520W Peak (170W RMS) 3" S-Series Hi-Res 2-Way Coaxial 4-ohm Shallow Car Speakers

-14.32%

$119.95

List price $140.00

EPICPRO8X main

AudioControl EPICPRO8X

700W Peak (500W RMS) 8" Epic Pro Series Pro Audio Midrange 4-ohm Speakers

H80C main

Cerwin-Vega H80C

900W Peak (300W RMS) 8" HED Series 2 Way Component 4-ohm Speaker System

-16.67%

$219.99

List price $263.99

H35 main

Cerwin-Vega H35

240W Peak (80W RMS) 3.5" Vega Series 2-Way Coaxial 4-ohm Speakers

-16.67%

$69.99

List price $83.99

Limited time!
CF-275mt main

JL Audio CF-275mt

60W RMS 2.75" CF Series Custom-Fit Midrange 4-ohm Tweeters

12
-14.71%

$144.99

List price $169.99

Product Highlights


1000 watts, MonoBlock Class D Amplifier

Description


JL Audio brand icon

Authorized dealer

  • 1 pair of Differential-Balanced Inputs
  • Fully variable on-board crossover: (40Hz - 200Hz), selectable-slope LP (12 or 24 dB per octave)
  • 2-channel Preamp Outputs: independent active filter, parallel with amp filter or full-range
  • Bass EQ that is parametric with variable bass boost up to 15dB and you can use a Remote Bass Control (optional RBC-1)
  • Fully variable Infrasonic Filter: 24dB/octave from 15-60Hz
  • Output Polarity Reversal switch allows instant output polarity reversal
  • Dual mono speaker output connections that accepts up to 8 gauge wire
  • 12 volt and Ground connections accept 4 gauge wire or 2 gauge or 1/0 gauge

Specifications:

  • Rated Power: 1000 watts RMS at 1.5 ohm - 4 ohm (at 11V-14.5V)
  • THD at RMS Power: <0.05% @ 4 ohm
  • S/N Ratio: >95dB below rated power
  • Frequency Response: 5Hz - 500 Hz
  • Damping Factor: >500 at 4 ohm /50Hz
  • Input Range switchable from 200mV-2V RMS
    to 800mV-8V RMS
  • Dimensions: 19.7"L x 9.25"W x 2.36"H


Due to the complexities of installation, previous customer abuse, and improper installation, the JL Audio 1000/1 (BLACK) is now a repair only item whether defective on day 1 or day 365 of ownership.

Best selling similar products

NDA12001 small

NVX NDA12001

• 500 watts x 1 channel @ 4 ohm
• 850 watts x 1 channel @ 2 ohm
• 1200 watts x 1 channel @ 1 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(13)

$169.99

List price $239.99

ATOM 1300.1 PRO small

Deaf Bonce Apocalypse ATOM 1300.1 PRO

• 490 watts x 1 channel @ 4 ohm
• 780 watts x 1 channel @ 2 ohm
• 1300 watts x 1 channel @ 1 ohm
• Total RMS Power: 1300 watts
• Class D 1 ohm Stable Monoblock Amplifier

$199.90

List price $199.90

R2-1200X1 small

Rockford Fosgate Prime R2 R2-1200X1

• 400 watts x 1 channel @ 4 ohm
• 800 watts x 1 channel @ 2 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(23)

$449.99

List price $449.99

VAD17001v2 small

NVX VAD17001 v2 (VAD17001v2)

• 800 watts x 1 channel @ 4 ohm
• 1350 watts x 1 channel @ 2 ohm
• 1700 watts x 1 channel @ 1 ohm
• Total RMS Power: 1700 watts
• Class D 1 ohm Stable Monoblock Amplifier

(36)

$259.99

List price $335.99

CXA1200.1 small

Kicker CXA1200.1 (46CXA12001T)

• 600 watts x 1 channel @ 4 ohm
• 1200 watts x 1 channel @ 2 ohm
• 1200 watts x 1 channel @ 1 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(18)

$399.99

List price $429.99

VAD10001v2 small

NVX VAD10001 v2 (VAD10001v2)

• 420 watts x 1 channel @ 4 ohm
• 760 watts x 1 channel @ 2 ohm
• 1000 watts x 1 channel @ 1 ohm
• Total RMS Power: 1000 watts
• Class D 1 ohm Stable Monoblock Amplifier

(38)

$209.99

List price $227.99

JD1000/1 small

JL Audio JD1000/1

• 600 watts x 1 channel @ 4 ohm
• 1000 watts x 1 channel @ 2 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable Monoblock Amplifier

(25)

$429.99

List price $429.99

CXA400.1 small

Kicker CXA400.1 (46CXA4001T)

• 150 watts x 1 channel @ 4 ohm
• 300 watts x 1 channel @ 2 ohm
• 400 watts x 1 channel @ 1 ohm
• Total RMS Power: 400 watts
• Class D 1 ohm Stable Monoblock Amplifier

(10)

$199.99

List price $219.99

VADM1 small

NVX VADM1 v2 (VADM1v2)

• 240 watts x 1 channel @ 4 ohm
• 400 watts x 1 channel @ 2 ohm
• 600 watts x 1 channel @ 1 ohm
• Total RMS Power: 600 watts
• Class D 1 ohm Stable Monoblock Amplifier

(16)

$189.99

List price $239.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
1000 watts x 1 channel
RMS Power @ 2 ohms
1000 watts x 1 channel
RMS Power @ 1 ohm
(at 1.5 ohms) 1000 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
1 - Mono
Total RMS Power Output
1000 watts
Minimum Impedance Unbridged
1.5 ohm
THD at Rated RMS Power
0.05%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
40 - 200 Hz
Low-Pass Crossover Frequency
40 - 200 Hz
Signal-to-Noise Ratio
95 dB
Bass Boost
0 - 18 dB
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
100A x 1

Item Details


Manufacturer:

Model Number:

1000/1-BLACK

Weight:

22.00lbs

Internal SKU:

jl10001-black

Internal Product ID:

9896

Product and How-to Videos


Customer Ratings & Reviews


JL Audio 1000/1 (BLACK SPECIAL EDITION) thumbnail image

5 star
50%
4 star
50%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

great amp

One of th best amps ever. Will push 2 L7 15s to the breaking point with no problem. I've done it twice:)

By jesse on September 20, 2012

2 found this helpful


Decent amp

This amp is a very good amp although its discontinued.

By Jamie on November 4, 2020
