Precision Power (PPI) TRAX4.1200D (trax41200d) 1200W Max 600W

Precision Power TRAX4.1200D

1200W Max (600W RMS) Series 2-ohm Stable 4-Channel Class-D Amplifier

1200W Max (600W RMS) Series 2-ohm Stable 4-Channel Class-D Amplifier

• 100 Watts RMS x 4 @ 4 ohms
• 150 Watts RMS x 4 @ 2 ohms
• 300 Watts RMS x 2 @ 4 ohms, Bridged
• Total Peak Power: 1200 Watts
• High and Low Pass Filters
• RCA Preamp Outputs
• Aluminum Heatsink
• Dimensions: 9.75" W x 11.75" L x 2.5" H

We apologize

This item has been discontinued

DESCRIPTION
Precision Power (PPI)

Authorized dealer

General Features:

  • Precision Power Trax Series TRAX4.1200D
  • Class-D Full Range 2 ohm Stable 4-Channel Amplifier
  • RMS Power Rating:
    • 4 ohms: 100 watts x 4 chan.
    • 2 ohms: 150 watts x 4 chan.
    • 1 ohm: ------------N/A------------
    • Bridged, 4 ohms: 300 watts x 2 chan.
  • Total power output: 1200 watts
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Soft start turn-on
  • 4/3/2 channel operation
  • Preamp RCA outputs to daisy chain multiple amps
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Dual speaker terminals simplify the hookup of multiple speakers
  • Heavy duty aluminum alloy heat-sink
  • Input sensitivity: 200mV - 6V
  • Variable high-pass filter: 120 - 3000 Hz
  • Variable low-pass filter: 50 - 250 Hz
  • Fuse Rating: 35 A x 2
  • 4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
  • Dimensions: 9.75"W x 11.75"L x 2.5"H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
FEATURES & SPECS
Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 4 channels
RMS Power @ 2 ohms
150 watts x 4 channels
Bridged RMS Power
300 watts x 2 channels
Amplifier Specifications
Amplifier Series
Trax
Marine Certified
Amplifier Class
D
Number of Channels
4
Total Peak Power Output
1200 watts
Total RMS Power Output
600 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohms
Minimum Impedance Bridged
4 ohms
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
120 - 3000 Hz
Low-Pass Crossover Frequency
50 - 250 Hz
Bass/Gain Remote
No
Fuse Rating
35A x 2
Total Fuse Rating
70
Strappable
Yes
CEA-2006 Compliant
No
Authorized Dealer
Authorized Dealer
Authorized Dealer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer
