Rockford Fosgate M2-200X2

Specifications:

• Rockford Fosgate M2-200X2 2-Channel Element Ready Amplifier
• Power Ratings:
• 50 Watts x 2 @ 4 ohms
• 100 Watts x 2 @ 2 ohms
• 200 Watts x 1 @ 4ohms Bridged/Mono
• Dynamic Power Ratings:
• 60 Watts x 2 @ 4 ohms
• 107 Watts x 2 @ 2 ohms
• 215 Watts x 1 @ 4 ohms Bridged/Mono
• Frequency Response: 20 Hz - 20 kHz
• Low-Level Input Sensitivity: 150 mV - 4 V
• High-Level Input Sensitivity: 450 mV - 12 V
• Total Harmonic Distortion (THD+Noise): <1.0%
• Low-Level Inputs: 2 RCA
• High-Level Inputs: 4-Pin Molex
• Low-Level Outputs: 2 RCA
• High-Pass Crossover: 50 Hz - 250 Hz @ 12dB/Octave Butterworth
• Low-Pass Crossover: 50 Hz - 250 Hz @ 12dB/Octave Butterworth
• All-Pass Crossover: Yes
• 4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
• Recommended Fuse (not included): 30 A

General Features:

• Full-Range Efficient Class-D
• Features C.L.E.A.N. circuitry to help you adjust your gain settings
• UV stable powder coated cast aluminum heatsink
• Zinc Nickel-plated Marine grade brass connection terminals
• C.L.E.A.N. input/output clip detection and indicator LEDs
• MEHSA 4 (Maximum Efficiency Heat Sink Application)
• NOMAD: a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.
• Optimized using AudioGraph PowerCube measurement tool
• Focused mass heatsink design
• Top Mounted Control Panel
• Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
• Short Circuit & Over Current Protection
• Variable Infrasonic Filter
• Integrated Power and Speaker Terminals
• Balanced Differential Inputs via Speaker Line or RCA Inputs
• RCA pass-thru outputs
• Integration with OEM and Aftermarket Radios
• "Auto-Sense" turn-on with remote out (high level in)
• Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
• Low Impedance Stability
• Proprietary testing using RATS (Rockford Automated Testing System)
• CEA-2006 Compliant & CE Compliant
• Dimensions: 1.9"W x 6.8"D x 8.1"H
