Product highlights

PDX Series 4-Channel Car Amplifier • Class D • 400 Watts RMS • 100 Watts x 4 Chan. RMS • Variable High-Pass and Low-Pass Filter • Blue LED Power/Status Indicator • Compact Size

Learn more about the LS-pdxf4-RB

Product Highlights

PDX Series 4-Channel Car Amplifier • Class D • 400 Watts RMS • 100 Watts x 4 Chan. RMS • Variable High-Pass and Low-Pass Filter • Blue LED Power/Status Indicator • Compact Size

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

PDX Series 4-Channel Class D Car Amplifier
RMS Power Rating (@ 14.4V):
- 4 ohm: 100 watts x 4 chan.
- 2 ohm: 100 watts x 4 chan.
- Bridged, 4 ohm: 200 watts x 2 chan.
Total RMS output: 400 watts
DC-DC PWM Power supply with STAR circuitry
Blue LED power/status indicator conveniently located on the top
Discrete pre-amp stage
6-Layer glass epoxy PC board
Automatic over-current protection system
Soft start turn-on prevent initial system popping
4/3/2 channel operation
System Protection circuitry keeps the amp running properly
Large aluminum alloy heatsink for extreme heat dissipation
Gold-plated RCA level inputs
Proprietary screw terminals ensure a solid and secure connection
Input sensitivity:0.2-4 V with input level
Variable high-pass filter (30-400 Hz, 12 dB/octave)
Variable low-pass filter (30-400 Hz, 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 5-100,000 Hz
Dimensions: 8-9/16"D x 10-1/8"W x 2"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
90-Day Sonic Electronix warranty

Alpine products are warranted solely by Sonic Electronix, Inc. under the same period and terms as the original Alpine warranty. Sonic Electronix is not an Authorized Alpine Dealer and Alpine requires all merchandise purchased by Sonic Electronix customers to be returned solely to Sonic Electronix. Alpine products are also covered by our Standard Return Policy for returns on exchanges or refunds within 30 days from the date of purchase.

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 4 channel

RMS Power @ 2 ohms

100 watts x 4 channel

Bridged RMS Power

200 watts x 2 channel

Amplifier Specifications

Amplifier Class

Number of Channels

4-Channel

Total RMS Power Output

400 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.003%

Speaker Level Inputs

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

30 - 400 Hz

Low-Pass Crossover Frequency

30 - 400 Hz

Signal-to-Noise Ratio

95 dB

Remote bass/level controller

Fuse Rating

30A x 2

Warranty and Return Policy

Parts Warranty Duration

90 days

Labor Warranty Duration

90 days

Warranty Provider

Sonic Electronix
