Diamond Audio D3 400.4

D3 Series 4-Channel Amplifier D3400.4

Product videos
highlight-star-icon

Black Anodized Heatsink • Raised Diamond Audio logo • 88W x 4 @ 2 Ohms RMS • 182W x 2 @ 4 Ohms RMS Bridged • 0 - 18dB Bass Boost • Built in crossovers

Learn more about the d34004

We apologize

This item has been discontinued

Product Highlights


Black Anodized Heatsink • Raised Diamond Audio logo • 88W x 4 @ 2 Ohms RMS • 182W x 2 @ 4 Ohms RMS Bridged • 0 - 18dB Bass Boost • Built in crossovers

Description


  • Black anodized aluminum finish
  • Raised Diamond Audio Technology logo
  • Variable High/Low pass crossover (55 - 550 Hz, 12 dB/Oct)
  • Varible bass boost (0 - 18dB @ 45 Hz)
  • Adjustable input level controls with ground loop isolation (500mV - 5V)
  • PWM MOSFET Power supply with low AM RFI and protection circuits for overheating and sepaker shorts
  • RCA Inputs: 2 pair
  • Gold-plated input/output connectors and an external automotive type fuse
  • Remote turn-on with "soft start" musting to prevent "thump"
  • Dimensions: 13" L x 8-1/2" W x 2-1/4" H
  • 1-year SonicElectronix.com warranty

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
57 watts x 4 channel
RMS Power @ 2 ohms
88 watts x 4 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
182 watts x 2 channel
Amplifier Specifications
Number of Channels
4-Channel
Total RMS Power Output
364 watts
Minimum Impedance Unbridged
2 ohms
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.05%
Speaker Level Inputs
No
Preamp Outputs
No
Signal-to-Noise Ratio
100 dB
Bass Boost
0 - 18 dB
Fuse Rating
40A
Warranty and Return Policy

Item Details


Manufacturer:

Model Number:

D3-400.4

Weight:

12.00lbs

Internal SKU:

d34004

Internal Product ID:

2997
