See all parts that fit your 1990 Trooper

SPL GRLA840/4

840W 4-Channel Class A/B Gorilla Series Car Amplifier

SPL
Shop all SPL
Product videos
highlight-star-icon

Gorilla Series 4-Channel Car Amplifier • 80W x 4 Chan. @ 4 Ohm • 95W x 4 Chan. @ 2 Ohm • Bridged 190W x 2 Chan. @ 4 Ohm • Pulse Width Modulation Circuitry • Tri-Mode Capable • LED Power Indicators • Level Inputs

Learn more about the grla8404

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

gla4900 thumbnail

SPL GLA4-900

OUR PRICE: $64.99

View item
NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
51KSC404 main

Kicker KSC4 (51KSC404)

300W Peak (150W RMS) 4" KS Series 2 Way Coaxial 4-ohm Speakers

3
-16.67%

$99.99

List price $119.99

Product Highlights


Gorilla Series 4-Channel Car Amplifier • 80W x 4 Chan. @ 4 Ohm • 95W x 4 Chan. @ 2 Ohm • Bridged 190W x 2 Chan. @ 4 Ohm • Pulse Width Modulation Circuitry • Tri-Mode Capable • LED Power Indicators • Level Inputs

Description


SPL brand icon

Authorized dealer

  • Gorilla Series 4-Channel Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 80 watts x 4 chan.
    • 2 ohm: 95 watts x 4 chan.
    • Bridged, 4 ohm: 190 watts x 2 chan.
  • Max power output: 840 watts
  • MOSFET power supply
  • Pulse width modulation circuitry
  • Remote bass level input (remote level control sold separately)
  • LED power indicators
  • Bass Boost (0-18 dB bass boost at 45 Hz)
  • Tri-Mode capable
  • 4/3/2 channel operation
  • 2 Ohm stereo, 4 ohm mono stable
  • Preamp RCA outputs
  • 3-Way system protection circuitry (short, thermal and overload)
  • Gunmetal gray anodized finish with chrome accents
  • Heavy duty aluminum alloy heatsink
  • RCA level inputs
  • Screw terminals
  • Low level inputs (200mV-8V)
  • Variable high-pass filter (40-250 Hz, 12 dB/octave)
  • Variable low-pass filter (40-250 Hz, 12 dB/octave)
  • Frequency response: 10-30,000 Hz
  • Dimensions: 10"L x 8-1/4"W x 2-1/4"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Product history:

SPL GLA4-900 thumbnail
(newest, current model)
SPL GRLA840/4 thumbnail
(previous model, replaced by SPL GLA4-900)

Loading...
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

DEH-S7200BHS main

Pioneer DEH-S7200BHS

Single DIN CD Receiver with Bluetooth, HD Radio and SiriusXM Ready

2
-10.72%

$249.99

List price $280.00

XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28

Best selling similar products

VADM4v2 small

NVX VADM4 v2 (VADM4v2)

• 80 watts x 4 channel @ 4 ohm
• 125 watts x 4 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(41)

$209.99

List price $239.99

NDA6004 small

NVX NDA6004

• 100 watts x 4 channel @ 4 ohm
• 160 watts x 4 channel @ 2 ohm
• Bridged: 320 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(14)

$159.99

List price $215.99

VAD10004v2 small

NVX VAD10004 v2 (VAD10004v2)

• 150 watts x 4 channel @ 4 ohm
• 250 watts x 4 channel @ 2 ohm
• Bridged: 500 watts x 2 channel @ 4 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(25)

$279.99

List price $335.99

RD400/4 small

JL Audio RD400/4

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 400 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(28)

$304.99

List price $379.99

MFA 4.220 small

Deaf Bonce MFA 4.220

• 220 watts x 4 channel @ 4 ohm
• 330 watts x 4 channel @ 2 ohm
• Bridged: 660 watts x 2 channel @ 4 ohm
• Total RMS Power: 1320 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$289.90

List price $289.90

JD400/4 small

JL Audio JD400/4

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 400 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(34)

$299.99

List price $299.99

MFA 4.180 small

Deaf Bonce MFA 4.180

• 180 watts x 4 channel @ 4 ohm
• 270 watts x 4 channel @ 2 ohm
• Bridged: 540 watts x 2 channel @ 4 ohm
• Total RMS Power: 1080 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$259.90

List price $259.90

MVPA4 small

NVX MVPA4

• 100 watts x 4 channel @ 4 ohm
• 150 watts x 4 channel @ 2 ohm
• Bridged: 300 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(70)

$279.99

List price $383.99

MDX2000.4 2 Ohm small

PRV Audio MDX2000.4 2 Ohm

• 330 watts x 4 channel @ 4 ohm
• 500 watts x 4 channel @ 2 ohm
• Bridged: 1000 watts x 2 channel @ 4 ohm
• Total RMS Power: 2000 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$219.91

List price $274.89

AP200/4BT small

JL Audio AP200/4BT

• 40 watts x 4 channel @ 4 ohm
• 50 watts x 4 channel @ 2 ohm
• Bridged: 100 watts x 4 channel @ 4 ohm
• Total RMS Power: 200 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$549.99

List price $659.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
80 watts x 4 channel
RMS Power @ 2 ohms
95 watts x 4 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
190 watts x 2 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
4-Channel
Total Peak Power Output
840 watts
Total RMS Power Output
380 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.02%
Speaker Level Inputs
No
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
50 - 500 Hz
Low-Pass Crossover Frequency
30 - 250 Hz
Signal-to-Noise Ratio
97 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
No
Fuse Rating
25A x 1
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

SPL

Model Number:

GRLA840/4

Weight:

6.80lbs

Internal SKU:

grla8404

Internal Product ID:

37254

Product and How-to Videos


Customer Ratings & Reviews


SPL GRLA840/4 thumbnail image

5 star
50%
4 star
0%
3 star
0%
2 star
50%
1 star
0%



Durability
3
Value
4.5
Features
3.5
Design
3.5
Usability
3.5

Customer Reviews

Sort by:

Loading...

excellent value for the money

I love this amp. It has guts, power and it can push more than stated. I had it pushing 10 speakers: 2-6x9, 2-5x7, 6-Pyle Plus 1" dome tweeters. I have not had any problem with this amp at all. It does not even get hot. I highly recommend this product. The SPL-GRLA840/4 sounds great.

By bubba j on May 17, 2012

4 found this helpful


It's ok

It's great till it overheats. I sent mine back. Doesn't push the power it claims!

By got8 12s on March 22, 2012

2 found this helpful
