Cadence XAH125.4(xah1254) Class A/B Xenith 4-Channel Amplifier

Cadence XaH125.4 (Orange)

1000W, Xenith Series Class A/B 4-Channel Amplifier with Orange Chassis

1000W, Xenith Series Class A/B 4-Channel Amplifier with Orange Chassis

Xenith Series 4-Channel Class A/B Car Amplifier with Orange Chassis • 80W RMS x 4 Chan. @ 4 ohms • 125W RMS x 4 Chan. @ 2 ohms • 250W RMS x 2 Chan. @ 4 ohms Bridged • MOSFET Power Supply • 4-Way System Protection Circuitry • Variable High/Low-Pass Crossovers • Variable Bass Boost

We apologize

This item has been discontinued

DESCRIPTION
Cadence

Authorized dealer

  • Xenith Series 4-Channel Class A/B Car Amplifier with Orange Chassis
  • RMS Power Rating:
    • 4 ohms: 80 watts x 4 chan.
    • 2 ohms: 125 watts x 4 chan.
    • Bridged, 4 ohms: 250 watts x 2 chan.
  • Max power output: 1000 watts
  • MOSFET high speed power supply
  • LED power (green) and protect (red) indicators
  • Soft start system with mute and delay features
  • 4/3/2 channel operation
  • Speaker-level (high-level) inputs with signal sensing for automatic turn-on
  • Tiffany style RCA Jacks
  • Preamp RCA outputs to daisy chain multiple amps
  • 4-Way System Protection circuitry
  • Angled connection terminals
  • Computer optimized heatsink design
  • 3-Channel mixed mono capable
  • Bipolar studio-grade output stage transistors
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Input sensitivity:
    • Low level: 200mV-8V
  • Variable high-pass filter: (40-600 Hz)
  • Variable low-pass filter: (40-160 Hz)
  • Damping factor: >198 @ 100 Hz
  • Frequency response: 10-40,000 Hz
  • Chassis color: Orange
  • Chassis color also available in: Black
  • Dimensions: 13-5/16"L x 10-1/2"W x 2-5/8"H
  • 8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Note: Cadence has made an update to their line of Xa amplifiers. This new "H" series update has been redesigned for 30% better heat dissipation and they have added High Level OEM Integration Inputs and Tiffany Style Isolated RCA Jacks. Even though the amplifier is labeled as Xa125.4 you are indeed purchasing the new upgrade XaH125.4 amplifier. Please feel free to contact us regarding any concerns.

FEATURES & SPECS
Power Specifications - Full Range Channels
RMS Power @ 4 ohms
80 watts x 4 channels
RMS Power @ 2 ohms
125 watts x 4 channels
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
25 watts x 2 channels
Power Specifications - Full Range Channels
Peak Power @ 4 ohms
Peak Power @ 2 ohms
Peak Power @ 1 ohm
Bridged Peak/Max Power
Power Specifications - Subwoofer Channel
Peak Power @ 4 ohm
Peak Power @ 2 ohms
Peak Power @ 1 ohm
Amplifier Specifications
Amplifier Series
Marine Certified
Amplifier Class
AB
Number of Channels
4
Total Peak Power Output
1000 watts
Total RMS Power Output
500 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohms
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.1%
Speaker Level Inputs
Yes
Preamp Outputs
2 pairs
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
40 - 600 Hz
Low-Pass Crossover Frequency
40 - 160 Hz
Signal-to-Noise Ratio
97 dB
Channel Separation
50 dB
Bass/Gain Remote
No
Fan Cooled
No
Fuse Rating
30A x 2
Total Fuse Rating
Strappable
CEA-2006 Compliant
No
Sonic Certified Amplifier
Amp Bluetooth Connectivity
Hi-Res Certified
Authorized Dealer
Authorized Dealer
What is in the box?
WITB: Amplifiers
Other Accessory #1
Other Accessory #2
Other Accessory #3
Other Accessory #4
Other Accessory #5
Paperwork
Specials with this Item
Deals
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
