Cerwin-Vega HED300.2

300W MAX, HED Series 2-Channel Class AB Car Amplifier

Cerwin-Vega
Shop all Cerwin-Vega
Product videos
highlight-star-icon

HED Series 2-Channel Class AB Car Amplifier • 40W RMS x 2-Chan. @ 4 ohm • 75W RMS x 2-Chan. @ 2 ohm • 150W RMS x 1-Chan. @ 4 ohm Bridged • PWM MOSFET Power Supply • 12dB Vega Bass Boost • Low/High Level Inputs • Variable Low/High Pass Filters • Balanced/Unbalanced Speaker Inputs

Learn more about the hed3002

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
40-GM10 main

Metra 40-GM10

Connect your factory antenna to a new aftermarket radio for select 1958-2023 vehicles from GMC, Chevrolet, Pontiac

45
99-3001 main

Metra 99-3001 Dash Kit

Install a new Single-DIN car stereo in select 1988-1999 vehicles from Chevrolet, GMC trucks (Matte Black)

-42.32%

$14.99

List price $25.99

70-1855 main

Metra 70-1855 Wiring Harness

Install a new car stereo and retain factory amplifier in select 1988-1994 vehicles from Chevrolet, GMC, Buick

8
-43.25%

$20.99

List price $36.99

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

124
-33.36%

$79.96

List price $119.99

XBAF65 main

NVX XBAF65

Universal 6.5" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

117
-37.15%

$21.99

List price $34.99

DB462 main

Polk Audio DB462 (DB 462)

300W Peak (100W RMS) 4x6” DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

7
-9.99%

$90.00

List price $99.99

Limited time!
46CSC464 main

Kicker CSC46 (46CSC464)

300W Peak (100W RMS) 4x6” CS Series 2 Way Coaxial 4-ohm Speakers

15
-29.45%

$59.96

List price $84.99

Stage3 6427 main

JBL Stage3 6427 (STAGE36427AM)

350W Peak (70W RMS) 4x6” Stage3 Series 2-way 3-ohm Coaxial Car Speakers

1
-18.19%

$89.95

List price $109.95

51KSC4604 main

Kicker KSC46 (51KSC4604)

300W Peak (150W RMS) 4x6" KS Series 2 Way Coaxial 4-ohm Speakers

1
-16.67%

$99.99

List price $119.99

BE9ACP.WX main

Boss Elite BE9ACP.WX

9" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto (SiriusXM Ready)

Product Highlights


HED Series 2-Channel Class AB Car Amplifier • 40W RMS x 2-Chan. @ 4 ohm • 75W RMS x 2-Chan. @ 2 ohm • 150W RMS x 1-Chan. @ 4 ohm Bridged • PWM MOSFET Power Supply • 12dB Vega Bass Boost • Low/High Level Inputs • Variable Low/High Pass Filters • Balanced/Unbalanced Speaker Inputs

Description


Cerwin-Vega brand icon

Authorized dealer

Affordable Power with Cerwin-Vega HED Amplifiers

The HED300.2 from Cerwin-Vega is the perfect amplifier when looking to add some power to some upgraded car speakers when improving you car audio system. Due to its bridgeable feature this amplifier can even be used to power up a single HED124 Single 4 ohm subwoofer. This HED series 2-channel amplifier features both low-level RCA inputs and high-level speaker inputs giving it the versatility to be integrated into any vehicle regardless of the car audio system being used. The HED amplifier is equipped with low and high-pass filters to better fine tune all the frequencies in your car audio system and thus get the best sound reproduction possible and that better suits your personal needs. The Vega Boost will add 0-12dB bass boost that can be controlled conveniently from the front of the vehicle with an additional remote bass level control. With a high density alloy heatsink for heat dissipation and 3-Way System Protection circuitry, this HED amplifier will continue to play safely for long periods of time without causing damage to any device or even to its self. So if you want power and efficiency at an affordable price then look no further than the HED300.2 Cerwin-Vega car amplifier.

  • HED Series 2-Channel Class AB Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 40 watts x 2 chan.
    • 2 ohm: 75 watts x 2 chan.
    • Bridged, 4 ohm: 150 watts x 1 chan.
  • Max power output: 300 watts x 1 chan.
  • PWM MOSFET power supply
  • Remote bass level input (remote level control sold separately)
  • LED power (green) and protect (red) indicators
  • Vega Bass Boost (0 to +12 dB bass boost at 45 Hz)
  • Soft Start Turn-on
  • 2/1 Channel operation
  • Speaker-level (high-level) inputs with signal sensing for automatic turn-on
  • Preamp RCA outputs to daisy chain multiple amps
  • 3-Way System Protection circuitry
  • High-density aluminum alloy heatsink for extreme heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Input sensitivity:
    • Low level: 122mV-5V
    • High level: 3.8V-20V
  • Crossover selection switch
  • Variable high-pass filter (50-250 Hz, 12 dB/octave)
  • Variable low-pass filter (50-250 Hz, 12 dB/octave)
  • Damping factor: >363 at 50 Hz
  • Frequency response: 20-49,000 Hz
  • Dimensions: 11-5/8"L x 9-7/16"W x 2-1/8"H
  • 8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website (SonicElectronix.com) when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Loading...

Fits 1988-98 Chevy Silverado/GMC Sierra Single Loaded Subwoofer Box DB 1042 DVC

Under-Seat Loaded Subwoofer Enclosure for select 1988-1999 vehicles from Chevrolet, GMC

15
-18.33%

$195.99

List price $239.98

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

124
-33.36%

$79.96

List price $119.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
40 watts x 2 channel
RMS Power @ 2 ohms
75 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
150 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
2-Channel
Total Peak Power Output
300 watts
Total RMS Power Output
150 watts
Maximum Input Gauge Size
8 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.08%
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
50 - 250 Hz
Low-Pass Crossover Frequency
50 - 250 Hz
Signal-to-Noise Ratio
108 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
15A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

HED300.2

Weight:

7.85lbs

Internal SKU:

hed3002

Internal Product ID:

39684
