Name: Pioneer GM-A5602 Open Box Complete
Brand: Pioneer
SKU: ls-gma5602-obc6
Price: 89.99 USD
Availability: Discontinued

by Pioneer

About
Specs & Details
Reviews
Add-ons
Related Searches

Pioneer GM-A5602 Open Box Complete Image 1 — Pioneer GM-A5602 Open Box Complete

Pioneer GM-A5602 Open Box Complete Image 2 — Pioneer GM-A5602 Open Box Complete

Pioneer GM-A5602 Open Box Complete Image 3 — Pioneer GM-A5602 Open Box Complete

Pioneer GM-A5602 Open Box Complete Image 4 — Pioneer GM-A5602 Open Box Complete

Pioneer GM-A5602 Open Box Complete Image 5 — Pioneer GM-A5602 Open Box Complete

Pioneer GM-A5602 Open Box Complete Image 6 — Pioneer GM-A5602 Open Box Complete

Product highlights

• Open Box Complete
• RMS: 150W x 2 @ 4 ohm, 225W x 2 @ 2 ohm, 450W x 1 @ 4 ohm
• Total Peak Power: 900W
• CEA-2006 Compliant
• Dimensions: 13-3/4"W x 8-1/2"L x 2-1/2"H

Learn more about the ls-gma5602-obc6

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Very Good Condition:
A Very Good Open Box used product represents a well-cared-for product that has seen only brief installation and/or limited use, but remains in great condition. The item is complete, unmarked, and undamaged, but may show some limited signs of wear. Original packaging, paperwork or protective wrapping may be missing or slightly damaged from the item being opened. Product works perfectly. Warranty details are included in the item description or comments.

A part that is fully functional but shows no sign of use outside of installation.

General Features:

Pioneer A-Series GM-A5602
Class-AB FullRange 2-Ohm Stable 2-Channel Amplifier
RMS Power Rating:

4 ohm: 150 watts x 2 chan.
2 ohm: 225 watts x 2 chan.
Bridged, 4 ohm: 450 watts x 1 chan.

Max power output: 900 watts.
CEA-2006 Compliant Amplifier
Pulse Width Modulated MOSFET power supply
Balanced Isolator Input Circuit
LED power (on) and protect (off) indicators
Soft start turn-on
2 or Mono channel operation
Speaker-level (high-level) inputs with Signal Sensing Turn-on
3-way protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heat-sink for extreme heat dissipation
Input sensitivity:

Low level: 300mV - 6.5V
High level: 3V - 26V

Frequency Response: 10 - 70,000 Hz
Total Harmonic Distortion (THD): <0.05%
Signal to Noise Ration: >96 dB
Selectable crossover modes: LPF / OFF
Variable crossover frequency 40 - 500 Hz, 12 dB/octave
Selectable Bass Boost: 0, +6 dB, +12 dB bass boost at 50 Hz
Fuse Rating: 30A x 2
4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
Dimensions: 13-3/4"W x 8-1/2"L x 2-1/2"H
30 Day Sonic Electronix Warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

150 watts x 2 channel

RMS Power @ 2 ohms

225 watts x 2 channel

Bridged RMS Power

450 watts x 1 channel

Power Specifications - Full Range Channels

Peak Power @ 4 ohms

300 watts x 2 channel

Peak Power @ 2 ohms

450 watts x 2 channel

Bridged Peak/Max Power

900 watts x 1 channel

Amplifier Specifications

Series

GM Series

Amplifier Class

A/B

Number of Channels

2-Channel

Total Peak Power Output

900 watts

Total RMS Power Output

450 watts

Maximum Input Gauge Size

Any Gauge with use of Spade Terminal AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Yes

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
Full (AP)

Low-Pass Crossover Frequency

40 - 500 Hz

Signal-to-Noise Ratio

>95 dB

Bass Boost

Selectable: 0dB / 6dB / 12dB

Remote bass/level controller

Fuse Rating

30A x 2

Strappable

Sonic Certified Amplifier

Not Tested

Warranty and Return Policy

Parts Warranty Duration

30 days

Labor Warranty Duration

30 days

Warranty Provider

Sonic Electronix
