** FINAL CLOSEOUT! ** Bazooka ELA100.2

500W Max, 2-Channel Amplifier

Bazooka
Shop all Bazooka
Product videos
highlight-star-icon

EL Series 2-Channel Class AB Car Amplifier • 115W x 2 chan. @ 4 ohm • 165W x 2 chan. @ 4 ohm • 330W x 1 chan. @ 4 ohm • 500W x 1 chan. Max • Tri-Mode Capable • Built-in LP/HP crossover

Learn more about the ela1002

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
TS-A1081F main

Pioneer TS-A1081F

460W Peak (100W RMS) 4” A Series 2-way 4-ohm Coaxial Car Speakers

3
-18.18%

$90.00

List price $110.00

DB402 main

Polk Audio DB402 (DB 402)

270W Peak (90W RMS) 4" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

4
-9.99%

$90.00

List price $99.99

C1-400x main

JL Audio C1-400x

70W RMS 4" C1 Series 2 Way Coaxial 4-ohm Car Speakers

8
51KSC404 main

Kicker KSC4 (51KSC404)

300W Peak (150W RMS) 4" KS Series 2 Way Coaxial 4-ohm Speakers

3
-16.67%

$99.99

List price $119.99

R14X2 main

Rockford Fosgate Prime R14X2

120W Peak (60W RMS) 4” Prime Series 2 Way Coaxial 4-ohm Speakers

14
STAGE245F main

JBL Stage2 45F (STAGE245F)

100W Peak (50W RMS) 6.5" Stage2 Gen 2 Series 2 Way Coaxial Speakers

-27.55%

$49.99

List price $69.00

Limited time!
46CSC44 main

Kicker CSC4 (46CSC44)

300W Peak (100W RMS) 4” CS Series 2 Way Coaxial 4-ohm Speakers

1
-29.45%

$59.96

List price $84.99

Limited time!
C2-400X main

JL Audio C2-400x

70W RMS 4" C2 Series 2-Way Coaxial 4-ohm Car Speakers

9
-13.16%

$164.99

List price $189.99

S2-S40 main

Alpine S2-S40

280W Peak (90W RMS) 4" S-Series Hi-Res 2-Way Coaxial 4-ohm Car Speakers

2
-15.42%

$109.95

List price $130.00

P142 main

Rockford Fosgate Punch P1 P142

120W Peak (60W RMS) 4" Punch Series 2 Way Coaxial 4-ohm Speakers

11

Product Highlights


EL Series 2-Channel Class AB Car Amplifier • 115W x 2 chan. @ 4 ohm • 165W x 2 chan. @ 4 ohm • 330W x 1 chan. @ 4 ohm • 500W x 1 chan. Max • Tri-Mode Capable • Built-in LP/HP crossover

Description


Bazooka brand icon

Authorized dealer

  • EL Series 2-Channel Class AB Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 115 watts x 2 chan.
    • 2 ohm: 165 watts x 2 chan.
    • Bridged, 4 ohm: 330 watts x 1 chan.
  • Max power output: 500 watts x 1 chan.
  • Remote bass level input (ELA-BCM remote level control sold separately)
  • LED power indicators
  • Tuned Bass EQ (0-12 dB bass boost at 45 Hz)
  • Tri-Mode Capable: for example, this allows you to run a pair of mid and tweeters in stereo and a subwoofer in mono mode at the same time.
  • Speaker-level inputs
  • Auxiliary output: allows easy daisy chain connection to an EL Bazooka Class D Amplifier or Amplified Bass Tube
  • Power Fusing: protects the amplifier against short circuits and excessive current
  • 3-way Protection: Thermal, Short Circuit, Overload
  • Variable high-pass filter (60-400 Hz)
  • Variable low-pass filter (60-400 Hz)
  • Heavy duty aluminum alloy heatsink
  • Chrome-plated RCA level inputs
  • Chrome-plated screw terminals
  • Frequency response: 20 - 22000Hz
  • Efficiency: 90 dB
  • Dimensions: 10-1/4"L x 10-1/4"W x 2-5/8"H
  • 8-gauge power and groud leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
115 watts x 2 channel
RMS Power @ 2 ohms
165 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
330 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
2-Channel
Total Peak Power Output
500 watts
Total RMS Power Output
330 watts
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
.03%
Speaker Level Inputs
Yes
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
60 - 400 Hz
Low-Pass Crossover Frequency
60 - 400 Hz
Signal-to-Noise Ratio
90 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
20A x 2

Item Details


Manufacturer:

Model Number:

ELA100.2

Weight:

8.00lbs

Internal SKU:

ela1002

Internal Product ID:

9326
