Name: Kicker IX500.4 (10IX500.4) Open Box
Brand: Kicker
SKU: LS-10ix5004-OB
Price: 204.99 USD
Availability: Discontinued

by Kicker

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

Kicker IX500.4 (10IX500.4) Open Box Image 1 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 2 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 3 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 4 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 5 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 6 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 7 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 8 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 9 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 10 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 11 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box Image 12 — Kicker IX500.4 (10IX500.4) Open Box

Kicker IX500.4 (10IX500.4) Open Box-video

Product videos

Product highlights

IX Series Class D Car Amplifier • 4-Channel Operation • 75W x 4 Chan. @ 4 ohm • 125W x 4 Chan. @ 2 ohm • 250W x 2 Chan. Bridged • 0-18 Bass Boost • Gold-Plated Terminals • Small Footprint • Low and High Pass Filters

Learn more about the LS-10ix5004-OB

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Class D KICKER Power

Introducing the newest line of Kicker amplifiers, the IX Series. For the first time ever in Kicker history, they have entered the world of full range Class D technology. The amplifiers have been carefully designed and engineered with the incredible attention to detail, intense research and development, as well as proprietary Kicker components that only Kicker amplifiers are made with. The result is a dependable and highly efficient Class D amplifier that can produce an enormous amount of power. The Kicker IX amplifiers also feature the smallest amp chassis that Kicker has ever manufactured. The compact size enables the amplifier to fit in the smallest compartments of the vehicle. These amps are so small that some installers have been able to put these amplifiers inside of a glove compartment! The amps are so efficient that they are able to run all day long with little current draw and very little heat generated. Even though the heat sink is less then 10" in length, the amps still are barely warm to the touch after hours of intense use. Kicker makes the choice easy. For a high-powered, highly efficient, and compact amplifier, choose the Kicker IX amplifiers.

Full Range Class D mean High Output

The four-channel IX amplifier is a one of a kind. Offering a full range of amplified frequencies across four audio channels. With the installation of this single amplifier, a vehicle can have all four speakers powered with Kicker power. For the Kicker IX500.4 amplifier that means 75 Watts x 4 Channels at 4 ohm, and an impressive 125 Watts x 4 Channels at 2 ohm! No matter what type of after market speakers are installed, the IX amp will provide plenty of clean power. Since the amplifier is bridgeable, it can be configured in 4 channels, 3 channels, or 2 channels. It also features an advanced 12 dB/octave electronic crossover for the finer acoustic tuning. Following Kicker's tradition of high output, each amp exceeds the rated power. That means the 500 Watts RMS is actually more than that. Each amplifier is tested, rated, and given a "birth sheet" in the Kicker factory that listed the tested power. Every amp exceeds the rated power. That just one more reason to choose Kicker!

Amplifier Features:

IX Series 4-Channel Class D Car Amplifier
RMS Power Rating:
- 4 ohm: 75 watts x 4 chan.
- 2 ohm: 125 watts x 4 chan.
- Bridged, 4 ohm: 250 watts x 2 chan.
Total RMS power output: 500 watts
Max Power output: 1000 Watts
High-efficiency nonregulated MOSFET power supply
LED power (blue) and protect (red) indicators
Variable Bass Boost (0 to +18 dB bass boost at 40 Hz)
Optional Kicker 10IXSM stacking mounts available for a clean install
Optional vinyl skins for personalizing heat sinks available
Super-small footprint for easy mounting, decreased weight, and increased cargo space
4/3/2 channel operation
Preamp RCA outputs
5-Way System Protection circuitry (thermal, overload, speaker short protection, undervoltage, amd overvoltage)
Heavy duty aluminum alloy heatsink for extreme heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Input sensitivity:
- Low level: 125mV-5V
- High level: 250mV-10V
Built-in electronic crossover for variable high-pass filters, low-pass filters, and off (bypass)
Variable high-pass filter (50-200 Hz, 12 dB/octave)
Variable low-pass filter (50-200 Hz, 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 20-20,000 Hz
Dimensions: 11-3/8"L x 7-7/8"W x 2-3/16"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Item is a part of Kicker ProFit Group
Authorized Internet Dealer
2-year Manufacturer's warranty

Extend your Kicker warranty to 3 Years when you install your new Kicker amplifier with a compatible Kicker power kit! For a limited time, you can register your Kicker amplifier and power kit to qualify for an additional year of coverage. This offer is only available through official Kicker dealers and will only last for a limited time. With this amplifier, the following power kits will qualify for the extended warranty program: Kicker 09PK4, Kicker CK4, Kicker 09ZCK4. and Kicker 09PKD1.

2011 Kicker Authorized Online Dealer and eBay Seller

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

75 watts x 4 channel

RMS Power @ 2 ohms

125 watts x 4 channel

Bridged RMS Power

250 watts x 2 channel

Amplifier Specifications

Amplifier Class

Number of Channels

4-Channel

Total Peak Power Output

1000 watts

Total RMS Power Output

500 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

<1%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

50 - 200 Hz

Low-Pass Crossover Frequency

50 - 200 Hz

Signal-to-Noise Ratio

85 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Warranty and Return Policy

Parts Warranty Duration

2 years

Labor Warranty Duration

2 years

Warranty Provider

Manufacturer
