Lanzar HTG237

1000W, 2-Channel Mosfet Amplifier with Low and High Pass Filter Controls

Lanzar
Shop all Lanzar
Product videos
highlight-star-icon

• Max Power Output: 500 watts x 2 Channel @ 4 ohm
• Variable Bass Boost
• Soft Start Turn-On
• Gain Adjustment

Learn more about the htg237

We apologize

This item has been discontinued


Loading...
DPX305MBT main

Kenwood DPX305MBT

Double DIN Digital Media Receiver with Bluetooth and Built-in Alexa (SiriusXM Ready)

15
-20.50%

$159.00

List price $200.00

Pioneer AVH-3500NEX

7" Single DIN Flip-Out Touchscreen CD/DVD Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

9
-10.75%

$829.99

List price $930.00

Product Highlights


• Max Power Output: 500 watts x 2 Channel @ 4 ohm
• Variable Bass Boost
• Soft Start Turn-On
• Gain Adjustment

Description


Lanzar brand icon

Authorized dealer

General Features:

  • Heritage Series 2-Channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 125 watts x 2 chan.
    • 2 ohm: 225 watts x 2 chan.
    • Bridged, 4 ohm: 1000 max watts x 1 chan.
  • Max power output, 4 ohm: 500 watts x 2 chan.
  • Gain adjustment
  • Bass boost circuit
  • LED power (green) and protect (red) indicators
  • Variable Bass Boost 0 to 12 dB bass boost
  • Soft start turn-on/turn-off
  • 2 or Mono channel operation
  • Nickel-plated RCA level inputs
  • Screw terminals
  • MOSFET switching power supply
  • Input sensitivity:200mV - 6V
  • Fixed high-pass filter (80 Hz,)
  • Variable low-pass filter (50-250 Hz)
  • Subsonic filter (24 dB at 15 Hz)
  • Frequency response: 45 Hz
  • 4/8 gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
  • Dimensions: 8.81"W x 9.84"D x 2.24"H
  • Authorized Internet Dealer
  • 1-year SonicElectronix.com Warranty

Loading...
REF507CF_2_MET-825601_2 main

2 Infinity REF507CF (INFSPKRF507CFUS) w/ Adapter Plates

390W Peak (130W RMS) 5.25" Reference Series 2-way 3-ohm Component Speaker System with Speaker Adapter Plates

3
-12.14%

$477.88

List price $543.88

BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3

Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
125 watts x 2 channel
RMS Power @ 2 ohms
255 watts x 2 channel
Amplifier Specifications
Number of Channels
2-Channel
Total Peak Power Output
1000 watts
Total RMS Power Output
450 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
<0.01%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Low-Pass Crossover Frequency
50 - 250 Hz
Signal-to-Noise Ratio
>90 dB
Channel Separation
>65 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
No
Fuse Rating
25A x 1
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

HTG237

Weight:

4.00lbs

Internal SKU:

htg237

Internal Product ID:

43987

Product and How-to Videos


Customer Ratings & Reviews


Lanzar HTG237 thumbnail image

5 star
40%
4 star
40%
3 star
0%
2 star
0%
1 star
20%



Durability
3.6
Value
4
Features
3.4
Design
3.4
Usability
4.6

Customer Reviews

Sort by:

Loading...

True amp that sucks

This amp straight sucks hands down the rms rating for it to be bridged at 4ohm@1000watts produce a sound of 250 watts i do not recommend this amp at all.

By Thorn Santos on February 19, 2012

20 found this helpful


Does the job!

I have this hooked up to 2 MB Quart RLP304 12 inch subs and it hits really hard. It produces the type of bass that takes your breath away. I have only had one problem with it overheating and that is when I was testing to see how long it could go on full blast. Overall I am very happy with this product. It is small and easy to add to a custom system with limited space. The one thing I wish it had was a remote bass control. Other than that, I like it a lot.

By JoJo84 on July 30, 2012

15 found this helpful


Great Value!

Amp works good, doesnt over heat, but I don't blast my music or over extend the bass so... It was easy to set up, and I haven't had any problems w/ it.

By Rodney on June 8, 2014

14 found this helpful


great value

I've owned a few lanzar amps and I never had any trouble with them. I bought this lanzar as a highs amp and it's doing its job. it sounds great I even put it on my 3 kicker cvrs and I was surprised it put out good bass too.

By M.C on August 19, 2013

13 found this helpful


great product
