Crunch PZ1800.4

1800W PowerZone Series 4-Channel Car Audio Amplifier

Crunch
Shop all Crunch
Product videos
highlight-star-icon

• 1800 Watts Max
• 400 Watts x 4-Chan. @ 2 Ohm
• 4-Way System Protection
• Selectable Highpass/Lowpass Filters

Learn more about the pz18004

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

28
-17.08%

$199.00

List price $240.00

DEH-S7200BHS main

Pioneer DEH-S7200BHS

Single DIN CD Receiver with Bluetooth, HD Radio and SiriusXM Ready

2
-10.72%

$249.99

List price $280.00

XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28
TS-A1081F main

Pioneer TS-A1081F

460W Peak (100W RMS) 4” A Series 2-way 4-ohm Coaxial Car Speakers

3
-18.18%

$90.00

List price $110.00

DB402 main

Polk Audio DB402 (DB 402)

270W Peak (90W RMS) 4" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

35
-9.99%

$90.00

List price $99.99

Product Highlights


• 1800 Watts Max
• 400 Watts x 4-Chan. @ 2 Ohm
• 4-Way System Protection
• Selectable Highpass/Lowpass Filters

Description


Crunch brand icon

Authorized dealer

General Features:

  • PowerZone Series 4-Channel Class A/B Car Amplifier
  • Max Power Rating:
    • 4 ohm: 225 watts x 4 chan.
    • 2 ohm: 400 watts x 4 chan.
    • Bridged, 4 ohm: 900 watts x 2 chan.
  • Rugged Pulse Width Modulated MOSFET power supply for Instant Maxx Power Output
  • Carbon Fiber effect body with chrome Crunch logo
  • Exponential variable-power supply (EXVP) for efficient DC to AC conversion
  • LED power (green) and protect (red) indicators
  • Variable Bass Boost (0 to +9 dB bass boost at 45 Hz)
  • Speaker level inputs for
  • Soft Start Turn-on
  • 4/3/2/1 channel operation
  • Speaker-level (high-level) inputs with signal sensing for automatic turn-on
  • Illuminated badge and heatsink
  • Preamp RCA outputs to daisy chain multiple amps
  • 4-Way System Protection circuitry (DC, thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Silver-plated RCA level inputs
  • Silver-plated screw terminals
  • Input sensitivity:
    • Level: 200mV-5V
  • Variable high-pass filter (60-12,000 Hz)
  • Variable low-pass filter (30-250 Hz)
  • Damping factor: >180
  • Frequency response: 30-13,000 Hz
  • Dimensions: 14-3/16"L x 9-1/2"W x 2-1/8"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Product history:

Crunch PZ1800.4 thumbnail
(newest, current model)
Crunch PZA1600.4 thumbnail
(previous model, replaced by Crunch PZ1800.4)
Crunch PZT1400.4 thumbnail
(previous model, replaced by Crunch PZA1600.4)
Crunch P1400.4 thumbnail
(previous model, replaced by Crunch PZT1400.4)

Best selling similar products

NDA6004 small

NVX NDA6004

• 100 watts x 4 channel @ 4 ohm
• 160 watts x 4 channel @ 2 ohm
• Bridged: 320 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(22)

$159.99

List price $215.99

VADM4v2 small

NVX VADM4 v2 (VADM4v2)

• 80 watts x 4 channel @ 4 ohm
• 125 watts x 4 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(111)

$209.99

List price $239.99

RD400/4 small

JL Audio RD400/4

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 400 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(44)

$304.99

List price $379.99

Specifications & Details


Amplifier Specifications
Amplifier Class
A/B
Number of Channels
4-Channel
Total Peak Power Output
1800 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.05%
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
60 - 1200 Hz
Low-Pass Crossover Frequency
30 - 250 Hz
Signal-to-Noise Ratio
90 dB
Channel Separation
80 dB
Bass Boost
0 - 9 dB
Remote bass/level controller
No
Fuse Rating
40A x 2
Strappable
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

PZ1800.4

Weight:

9.30lbs

Internal SKU:

pz18004

Internal Product ID:

67950

Product and How-to Videos


  • Crunch PowerZone Amplifier | CES 2013
  • Crunch V-Drive Ground Pounder Car Amplifier | Maxxsonics @ CES 2013
  • How To Install an Amplifier: Car Amplifier Basics Part 2

Customer Ratings & Reviews


Crunch PZ1800.4 thumbnail image

5 star
55%
4 star
18%
3 star
18%
2 star
9%
1 star
0%



Durability
4.1
Value
4.5
Features
4
Design
4.4
Usability
4.6

Customer Reviews

Sort by:

Loading...

it is ok

The following review is for a previous version (P1400.4).

Does put out some power. But i'm doubtful that its 80 watts RMS per channel. I had 80 watt RMS audiobahns in the front and panasonic 35 watts RMS with pioneer tweeters. The audiobahns blew... The panasonics are still working along with the pioneers tweeters and still sound amazing. (Audiobahn speakers aren't great) Had this set up for about 6 months and then I noticed a noise. Checked everything, it was the amp. If I bumped it with my fist, the noise went away. Did that for about a week then I decided to bridge the rear terminals for an 8 inch sub. The amp popped after 20 minutes. The bass boost was at 0dB and gain 1/3 the way up on the rear channels.
And apparently Crunch has a different definition of 4 gauge terminals...I had to trim some 8 gauge just to fit them in there...
I recommend this amp for some descent 6x9's and it'll last if you don't abuse it. Don't bridge it. It'll get too hot.
If you like it loud and you are hard on your equipment like I am, look elsewhere and spend the Bill on something else. I replaced this amp with a Jensen (believe it or not) power 760 and it is amazing. I am achieving the same volume with the same amp settings that i had on the crunch and the jensen is half the price.... seriously.

By oldskewl on May 27, 2009

9 found this helpful


The following review is for a previous version (P1400.4).

Great cheap amp! Puts out a good amount of power. Doesnt draw to much amperage. Its not the clearest amp on the market, but worth the money.

By zach on August 14, 2008

8 found this helpful


This is greatt!!

The following review is for a previous version (P1400.4).

Hi there, i am using this amplifier with a pair of 6x9 pioneer 460 watts and a 1400 subwoofer pioneer and it sound so great!.

I had bridge the subwoofer and it is hitting so hard!

Just one amplifier and you will have a good sound!

This is great!!

By Moi on July 29, 2009

8 found this helpful


bad power

The following review is for a previous version (PZT1400.4).

Run it as a 2 channel is good but use it in a 4 channel its done and no sound control
I have a Jensen 720 got more power and control

By lee on February 9, 2011

6 found this helpful


Eh

The following review is for a previous version (P1400.4).

Well I bought the amp to run eminence on 2 channels and Subs on the other, for the first month it was pretty good until I found out the real rms of it. Then the tune nobs on the side stopped working so they got stuck on just all highs. And sonic says it needs a 4 gauge power and ground when 8 guage barely fits in.

By Troy on December 5, 2008

6 found this helpful


Crunch

The following review is for a previous version (P1400.4).

Crunch is what it is when you put it on High...I like this amp is good for the price i give it a 10 that was`up ..sounds good can complain .

By Angel on January 26, 2009

6 found this helpful


great buy

The following review is for a previous version (P1400.4).

excellent amp for the price, i have it hooked up to 2- 1200 watt pioneer subs (bridged at 700 rms each) and they work perfectly. never had a problem with overheating, and its never failed me yet!

By will on November 25, 2008

5 found this helpful


Its Loud!!!!

The following review is for a previous version (PZT1400.4).

I got it running @ 2 ohms on 2 channels on 4 250 watt rms Pops 6x9s and its at 1/4 gain. And on the remaining 2 channels I have 2 35 watt rms Pioneer 6 1/2s, 2 35 watt rms 4x6s and 2 sets of 100 watt rms tweets wired down to 4 ohms all running from a 2V output Pioneer deck and it all sounds clean!

By Debo on February 16, 2012

4 found this helpful


Great amp

The following review is for a previous version (P1400.4).

I am only using half of what this amp puts out and it is load. I am pushing music to tower speaker sets on my boat and at 80' with the boat running at speed, I can hear the music crystal clear. I can't wait to find some place to put the rest of what this amp has to offer.

By james on December 22, 2008

5 found this helpful


Great Product

The following review is for a previous version (PZA1600.4).

Amp looks good and does the job. Sleek red LEDs make it even more amazing. Only con is it does get a little toasty, but overall, I would by this amp again.
