Orion 8004

4-Channel Car Amplifier

Orion
Shop all Orion
Product videos
highlight-star-icon

800W 4 channel Amplifier • 200W x 4 channel power output at 2 Ohm • 100W x 4 channel power output at 4 Ohm • 2-way Highpass/Lowpass Xover • Intelli Bass

Learn more about the ori8004

We apologize

This item has been discontinued

Product Highlights


800W 4 channel Amplifier • 200W x 4 channel power output at 2 Ohm • 100W x 4 channel power output at 4 Ohm • 2-way Highpass/Lowpass Xover • Intelli Bass

Description


  • 4-channel car amplifier
  • Power Ratings:
    • 4 x 100w RMS @ 4 Ohms
    • 4 x 200w RMS @ 2 Ohms
    • 2 x 100w RMS + 1 x 400 @ 4 Ohms
    • 2 x 400w RMS @ 4 Ohms
  • Intelli Bass variable bass equalization (models 4004, 8004)
  • Intelli Q bass optimization circuit and remote gain option (model 7005 only)
  • 2-way active selectable crossovers and high-level inputs (model 4004)
  • Separately adjustable, variable 2-way active crossovers with proprietary Copy/Master control circuit for RCA outputs (models 8004, 7005)
  • Copy/Master feature supports high-pass, low-pass, or bandpass configuration and gain matching for multiple amp systems
  • Selectable 2/4 channel input (model 7005 features 2/4/6 channel selectable input)
  • 12/24 dB/octave variable low-pass filter (channel 5) and remote gain option
  • Heavy gauge direct-wire high current satin finish power and speaker terminals

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 4 channel
RMS Power @ 2 ohms
200 watts x 4 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
400 watts x 2 channel
Amplifier Specifications
Number of Channels
4-Channel
Total RMS Power Output
800 watts
Minimum Impedance Unbridged
2 ohms
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
<1%
Speaker Level Inputs
No
Preamp Outputs
1 pair
High-Pass Crossover Frequency
20 - 3000 Hz
Low-Pass Crossover Frequency
20 - 3000 Hz
Signal-to-Noise Ratio
85 dB
Bass Boost
0 - 16 dB
Remote bass/level controller
No
Fuse Rating
100A
Warranty and Return Policy

Item Details


Manufacturer:

Model Number:

8004

Weight:

26.00lbs

Internal SKU:

ori8004

Internal Product ID:

719

Product and How-to Videos


Customer Ratings & Reviews



5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
4.5
Features
5
Design
4.5
Usability
4.5

Customer Reviews

Sort by:

Loading...

Works like a champ

I'm running this amp to power my polk audio db components and it never skips a beat. Stays cool to the touch and never drops from it's rated power. Definitely recommended.

By Robert on March 27, 2006

16

found this helpful.

Rocks your world!!

Flexible is right - this amp has two sets of crossovers you can use, 2 seperate gains, and variable Q bass boost. I've got 2 of these; one running 2 12" Orion P2 subs in bridged mode and the other running seperate 2 tweets and 4 mids. I'm running at 1/2 gain with almost no noise from the amps and the spl is near concert level if I want it loud and very quiet at low level. Full gain has a little background noise but you won't hear it with the volume up - s/n is about 80 to 1 at full gain. 0 distortion. It's a nice looking unit pretty big and heavy. Uses 4 guage power and ground wires and high quality RCA connects. It's pretty impressive overall - nice beefy looks too.

By wesley on October 17, 2005

15

found this helpful.
