Pioneer GM-5200T R/B

FACTORY REFURBISHED

Pioneer
Shop all Pioneer
Product videos
highlight-star-icon

760 watts, 2-Channel Pioneer GM-5200T Amplifier • 125W x 2 chan. @ 4 Ohm • 190W x 2 chan. @ 2 Ohm • Bridged, 4 ohm: 380 watts x 1 chan. • speaker and preamp level inputs and outputs • CEA-2006 compliant

Learn more about the LS-gm5200t-RB

We apologize

This item has been discontinued

Product Highlights


760 watts, 2-Channel Pioneer GM-5200T Amplifier • 125W x 2 chan. @ 4 Ohm • 190W x 2 chan. @ 2 Ohm • Bridged, 4 ohm: 380 watts x 1 chan. • speaker and preamp level inputs and outputs • CEA-2006 compliant

Description


Pioneer brand icon

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

  • 760 Watt 2-Channel Pioneer GM-5200T Amplifier
  • RMS Power Output
    • 4 ohm: 125 watts x 2 chan.
    • 2 ohm: 190 watts x 2 chan.
    • Bridged, 4 ohm: 380 watts x 1 chan.
  • Selectable low-pass filter (80 Hz, 12 dB per octave)
  • Selectable bass boost (0, 6, 9, 12 dB at 50 Hz)
  • CEA-2006 compliant
  • speaker- and preamp-level inputs
  • fuse rating: 30A x 2
  • Signal-to-Noise ratio: 95 dB
  • Channel Separation: 70 dB
  • 8-gauge power / ground leads recommended
  • Dimensions: 1" D x 12" W x 2-3/8" H
  • 90 days SonicElectronix.com warranty

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
125 watts x 2 channel
RMS Power @ 2 ohms
190 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
380 watts x 1 channel
Amplifier Specifications
Number of Channels
2-Channel
Total RMS Power Output
380 watts
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
>1%
Speaker Level Inputs
Yes
Preamp Outputs
Yes
Low-Pass Crossover Frequency
10 - 80 Hz
Signal-to-Noise Ratio
95 dB
Channel Separation
70 dB
Bass Boost
0 - 12 dB
Fuse Rating
30A x 2

Item Details


Manufacturer:

Model Number:

GM-5200T-RB

Weight:

10.00lbs

Internal SKU:

LS-gm5200t-RB

Internal Product ID:

8452
