Cerwin-Vega H41200.4

1200W HED Series 4-Channel Class AB Amplifier

Product videos
highlight-star-icon

• RMS Power: 80W x 4 @ 4 ohm , 110 watts x 4 @ 2 ohm
• Total Peak Power: 1200W
• Variable Low-Pass Filter
• Pulse Width Modulated MOSFET Power Supply
• Heavy-Grade Aluminum Alloy Extruded Heatsink

Learn more about the h412004

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
XED650C main

Cerwin-Vega XED650C

600W Peak (70W RMS) 6.5" XED Series 2-Way 4-ohm Component Speaker System

28
-16.67%

$64.99

List price $77.99

S2-S65 main

Alpine S2-S65

480W Peak (160W RMS) 6.5" S-Series Hi-Res 2-Way Coaxial 4-ohm Car Speakers

5
-16.69%

$149.95

List price $180.00

XED525C main

Cerwin-Vega XED525C

500W Peak (60W RMS) 5.25” XED Series 2-Way 4-ohm Component Speaker System

8
-16.67%

$59.99

List price $71.99

Product Highlights


• RMS Power: 80W x 4 @ 4 ohm , 110 watts x 4 @ 2 ohm
• Total Peak Power: 1200W
• Variable Low-Pass Filter
• Pulse Width Modulated MOSFET Power Supply
• Heavy-Grade Aluminum Alloy Extruded Heatsink

Description


Cerwin-Vega brand icon

Authorized dealer

General Features:

  • HED Series 4-Channel Class AB Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 80 watts x 4 chan.
    • 2 ohm: 110 watts x 4 chan.
    • Bridged, 4 ohm: 220 watts x 2 chan.
  • Max Power Output: 1200W
  • Class AB Power Multi-Channel Topology Design
  • Heavy-Grade Aluminum Alloy Extruded Heatsink
  • Illuminated Ambient Lit Cerwin-Vega Logo
  • LED power (green) and protect (red) indicators
  • Power Supply Threshold: 10.0 VDC - 17.0 VDC
  • Total Harmonic Distortion: 0.1%
  • Signal to Noise Ratio (@1w): 85 dBa
  • Input Sensitivity: 0.2 mV - 6.0 V
  • Damping Factory: >70
  • Frequency Response: 10 - 45,000 Hz
  • Selectable Crossover: Full/HPF/LPF
  • Variable low-pass filter: 35 - 3500 Hz
  • Variable high-pass filter: 15 - 350 Hz
  • Variable Bass Boost (Rear Only): 0 - 9 dB
  • Fuse Rating: 30A x 2
  • 8 gauge power and ground wiring is recommended for installation
    • Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier
  • Dimensions: 8.875"W x 16.85"L x 2.187H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
Check out the Cerwin-Vega H41200.4 Owner's Manual
