Sound Storm Labs (SSL) SS10

600W Peak (300W RMS) 10" SS Series Single 4-Ohm Car Subwoofer

8
Sound Storm Labs (SSL)
Product videos
highlight-star-icon

• Peak Power: 600 watts
• RMS Power: 300 watts
• Fiber Injection Cone
• Foam Surround
• Impedance: Single 4 ohms
• Mount depth: 4-1/8"
• Sensitivity: 88 dB

Learn more about the ss10

We apologize

This item has been discontinued

Show me more products from this category
Go to Category

Product Highlights

• Peak Power: 600 watts
• RMS Power: 300 watts
• Fiber Injection Cone
• Foam Surround
• Impedance: Single 4 ohms
• Mount depth: 4-1/8"
• Sensitivity: 88 dB

Description

Sound Storm Labs (SSL)

Authorized dealer

Product Details:

  • 10" Single 4 ohms Labs SS Series Subwoofer
  • Power Handling:
    • Peak: 600 watts
    • RMS: 300 watts
  • Fiber Injection Cone
  • Foam Surround
  • 1.5" High Temperature Voice coil
  • 12 mm Xmax
  • Resonance Frequency (Fs): 32.3 Hz
  • Sensitivity: 88 dB
  • Sealed box volume: 1.15 cubic feet
  • Top-mount depth: 4-1/8"
  • Cutout diameter: 9-1/8"
  • Authorized Internet Dealer
  • Protective subwoofer grille: No
  • 1-year Manufacturer's Warranty

    • Priced Individually

Subwoofer Wiring Guide

Wiring Guide to Wire 1 Sound Storm Labs (SSL) SS10 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Sound Storm Labs (SSL) SS10 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Sound Storm Labs (SSL) SS10 Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 Sound Storm Labs (SSL) SS10 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details

Subwoofer Specifications
Series
Labs SS Series
Subwoofer Size
10"
Peak Power Handling
600 watts
RMS Power Handling
300 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohms
Voice Coil Diameter
1.5"
Sensitivity
88 dB
Xmax (millimeters)
12 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Fiber Injection
Woofer Surround
Foam
Magnet Structure
Subwoofer Grille
No
Re-Cone Kit Available
No
CTA-2031 Compliant
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Minimum Sealed Box Volume
1.15 cubic feet
Top-Mount Depth (Mounting Depth)
4-1/8"
Cutout Diameter
9-1/8"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
32.3 Hz
Equivalent Compliance (Vas)
72.06 liters
Total Speaker Q Value (Qts)
.505
Electrical Q Value (Qes)
.564
Mechanical Q Value (Qms)
4.82
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Subwoofers
Subwoofer
Other Accessory #6
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details

Manufacturer:

Sound Storm Labs (SSL)

Model Number:

SS10

Weight:

5.40lbs

Internal SKU:

ss10

Internal Product ID:

89590

Product and How-to Videos

Customer Ratings & Reviews

Sound Storm Labs (SSL) SS10
8
Rate or review product
5 star
63%
4 star
38%
3 star
0%
2 star
0%
1 star
0%
Durability
4.9
Value
5
Features
4.8
Design
4.9
Usability
5
Sort by:
Loading...

Great sound for the price

I bought two of these on sale to add some extra bass in my wife's car and was very surprised how good these sound for less then $30 each. if you are not going with a high powered system these are great for how cheap they are

By Douglas on March 24, 2015

24

found this helpful.
Helpful? Report abuse

Great value

I used these to replace my 10 inch house subwoofers that were blown. These work great. I would recomend these..

By Mike on April 19, 2018

5

found this helpful.
Helpful? Report abuse

Soundstorm 10

I grabbed these to restore some home speakers... They are an absolute steal at this price... I'm impressed

By Anonymous on September 2, 2019 checkmarkIcon Verified purchase

3

found this helpful.
Helpful? Report abuse

SoundStorm ssl 10

These hit pretty well. Don't use too much power & you'll be fine.

By Charles on July 8, 2016

3

found this helpful.
Helpful? Report abuse

SoundStorm (SSL) SS10

Bought 3 of these ssl subs and put them on a sealed box and i was surprised how well they slam for the price. Highly recommend purchasing. I have the 3 subs connected at a 1.3 ohm load on a 500 watt memphis 1 ohm stable amp and these slam nice for the price considering i only spent about $60 for all 3. If you are on a budget and want something cheap but that will sound nice buy these!

By Anonymous on June 30, 2018

2

found this helpful.
Helpful? Report abuse

Great value

This thing is basic when compared to others like it, but it really Shines on the price.

By Anonymous on October 3, 2018

2

found this helpful.
Helpful? Report abuse

Works great

Quality product at low price. I will recommend to all of my friends..

By Michael on May 4, 2018

2

found this helpful.
Helpful? Report abuse

Great

Very nicely made woofer....would buy again in a sec; thx sonic electronix

By Jonathan on March 20, 2018

2

found this helpful.
Helpful? Report abuse
