AudioControl LC-4.800

General Features:

• RMS Power Rating:
• 4 Ohm: 125 watts x 4 chan.
• 2 Ohm: 200 watts x 4 chan.
• Bridged: 400 watts x 2 chan.
• 4/3/2 channel operation
• Optional ACR-1 Assignable Remote Level & Preset Control
• Line-level and Speaker-level (high-level) inputs
• 4 balanced preamp inputs
• Signal summing
• Summable active speaker-level inputs (6 channels) for OEM integration
• Line level outputs to daisy chain multiple amplifiers
• 2 assignable preamp outputs
• Maximum Preamp Output: 8.5 V RMS
• AccuBASS Processing
• MILC Source Clip Detection - Maximized Input Level Control:
• assures the input signal avoids clipping and distortion
• Input Voltage Range: 250mV - 8V RMS
• GTO Signal Sense
• Premium OEM Integration
• Solid One-Piece Aluminum Chassis
• Adjustable Linkwitz-Riley Alignment crossovers: 30 - 300 Hz
• PFM Subsonic Filter: 32Hz
• Fuse Rating: 40A x 2
• Signal-to-Noise Ratio: 102dBa
• Total Harmonic Distortion: <0.1%
• Frequency Response: 10 Hz - 30 kHz
• 4 - 8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
• Dimensions: 9"W x 7.95"D x 2.1"H
• Authorized Internet Dealer
• 5 Year Manufacturer's Warranty

What's in the Box

• LC-4.800
• Speaker connectors
• Fuses
• Manual
• Warranty
