Name: JBL GTO1004
Brand: JBL
SKU: gto1004
Price: 229.99 USD
Availability: Discontinued
Rating: 4.7333 (15 reviews)

Shop all JBL

by JBL

About
Specs & Details
Product Videos
Reviews
Add-ons
Similar Products
Related Searches

Product videos

Product highlights

Grand Touring Series 4-Channel Class AB Car Amplifier • 100W x 4 chan. @ 4 ohms • 150W x 4 chan. @ 2 ohms • 150W x 4 chan. Max (4 ohms) • Bridgeable Operation • Preamp RCA outputs • Cast-Aluminum Heatsink

Learn more about the gto1004

Product Highlights

Description

Authorized dealer

Grand Touring Series 4-Channel Class AB Car Amplifier
RMS Power Rating:

4 ohms: 100 watts x 4 chan.
2 ohms: 150 watts x 4 chan.

LED power and protection indicators
Tuned Bass EQ (0-12 dB bass boost)
Bridgeable operation
Preamp RCA outputs
Cast-aluminum heatsink
Variable high-pass filter (32-320 Hz, 12 dB/octave)
Variable low-pass filter (32-320 Hz, 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 10-100000 Hz
Dimensions: 18-9/16"L x 10-3/8"W x 2-1/8"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Also can be found as: GTO-1004, GTO100.4
Authorized Internet Dealer
1-year Manufacturer's warranty

Product history:

	JBL GTO1004 (newest, current model)
	JBL GTO75.4II (previous model, replaced by JBL GTO1004)

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 4 channel

RMS Power @ 2 ohms

150 watts x 4 channel

Bridged RMS Power

300 watts x 2 channel

Power Specifications - Subwoofer Channel

RMS Power @ .5 ohm

Power Specifications - Full Range Channels

Peak Power @ 4 ohms

Peak Power @ 2 ohms

Peak Power @ 1 ohm

Bridged Peak/Max Power

Power Specifications - Subwoofer Channel

Peak Power @ 4 ohm

Peak Power @ 2 ohms

Peak Power @ 1 ohm

Peak Power @ .5 ohm

Amplifier Specifications

Series

Marine Certified

Amplifier Class

A/B

Number of Channels

Total RMS Power Output

600 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohms

Minimum Impedance Bridged

4 ohms

Frequency Response

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

32 - 320 Hz

Low-Pass Crossover Frequency

32 - 320 Hz

Signal-to-Noise Ratio

104 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Fan Cooled

Fuse Rating

25A x 3

Total Fuse Rating

Strappable

Sonic Certified Amplifier

Amp Bluetooth Connectivity

Hi-Res Certified

Low-Level Input Sensitivity

High-Level Input Sensitivity

What is in the box?

Paperwork

WITB: Amplifiers

Other Accessory #1

Other Accessory #2

Other Accessory #3

Other Accessory #4

Other Accessory #5

Other Accessory #6

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer

Customer Ratings & Reviews

Rate or review product

Overall rating distribution

5 star		80%
4 star		13%
3 star		7%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		4.8
Value		4.8
Features		4.8
Design		4.8
Usability		5

Customer Reviews

Sort by:

wow read this.

For the money what a great amp. Clean loud powerful and its sooo beautiful and sharp looking. People go nuts on how nice it looks and sounds in my car. JBL is great stuff. Mybe not top top of line but they really make some great car audio. You wont be dissapointed!

By charles on December 17, 2011

found this helpful.

Helpful? Report abuse

Awesome!

IT not only looks good but def delivers!! This is my first AMP I ever used for my internal 4 speakers and when my buddy told me how big of a difference it would make compared to running the speakers off the headunit, I could not believe it! Good STUFF!!! Only thing about it is that it was just a HAIR too long for where I was mounting it but I was able to improvise.

By Metal Dave on July 16, 2010

found this helpful.

Helpful? Report abuse

JBL GTO1004

Definetely the best buy i could ever made, power full reliabable easy to use and install .Great produt .

By MIKE on October 20, 2010

found this helpful.

Helpful? Report abuse

great amp

Good sound does not overheat.

By akwik6 on March 15, 2012

found this helpful.

Helpful? Report abuse

Great Value!

Works great, does not overheat even when its 100+ degrees outside and no cooler inside the vehicle. Clear crisp sound.

By Chris on February 22, 2011

found this helpful.

Helpful? Report abuse

Awesome!!!

This is a great product. A very high quality product and great bang for your buck.
Highly Recommended!!!

By Khushpreet on May 19, 2010

found this helpful.

Helpful? Report abuse

JBL

Jbl hands down when it comes to my highs. This amp puts out a ton of power and sounds great. Works well keeping up with my orion lows.

By brandon on January 6, 2011

found this helpful.

Helpful? Report abuse

WOW!!! Sound quality and power!!!

This is a huge amp. Over a foot long so be aware if space is an issue for you. If it's not then get this amp. For the money it won't be beat. JBL makes very high end audio equipment and this amp is nothing short of high end. It makes my Type R components and rear coaxials scream with authority. If you want a powerhouse quality 4 channel speaker amp for a reasonable price buy this one.

By Shaun on February 16, 2010

found this helpful.

Helpful? Report abuse

good but could be better

Honestly this amp is wicked. it pushes out way more than you might expect. However the way that JBL built the RCA inputs is incredibly cheap. They're not even soldered on. If you pull on them they pop right out. not cool. I figured this out when I unplugged a pair of monster RCA cables.

By keith on July 21, 2010

found this helpful.

Helpful? Report abuse

I respect it

Perfect amp to bring the noise when it comes to your highs without the extra bass or distortion in the levels

By KillaFeeItwter on April 18, 2011

found this helpful.

Helpful? Report abuse

See all 15 reviews
