** BELOW COST!! ** Xtant X604

4-Channel Amplifier

Xtant
Shop all Xtant
Product videos
highlight-star-icon

600 Watt 4-Channel Amplifier • 150W x 4 @ 2 Ohm • Stainless Steel Finish • 3-Way Protection Circuitry • PWM MOSFET Power Supply • LED Status Indicators • RCA Outputs

Learn more about the x604

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28

Product Highlights


600 Watt 4-Channel Amplifier • 150W x 4 @ 2 Ohm • Stainless Steel Finish • 3-Way Protection Circuitry • PWM MOSFET Power Supply • LED Status Indicators • RCA Outputs

Description


  • 600W RMS 4-channel Amplifier
  • Stainless Steel Cover
  • Fully Regulated PWM MOSFET Power Supply
  • 4 Modular Expansion Ports: Used for docking Xtant's signal processors
  • Forced Convection Cooling
  • Balanced / Floating Input: Helps to eliminate noise
  • Protection Circuitry: Thermal, Overcurrent, and Low Voltage Protection
  • Status LEDs: Red On, Yellow Overcurrent Protection, Orange Thermal Protection
  • Input Sensitvity: 100mV - 8.5V RMS Unbalanced / 100mV - 17V Balanced
  • Input to Line Output Gain: -20 - 20 dB, Selecable 10 dB Steps
  • On-Board Crossvoer: 12 or 24 dB/Oct Butterworth
  • Line Outputs: Yes, High Pass, or Bypass Mode
  • Operational Voltage: 11 - 15V
  • Crossover Variable From 10 Hz - 5khz in 12 Steps
  • Dimensions: 20-11/16" L x 10-5/16" W x 2-3-16" H
  • 1-year SonicElectronix.com warranty

120 Amp External Fuse Required!


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

124
-33.36%

$79.96

List price $119.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

REF6532IXAM main

Infinity Reference REF6532IXAM

360W Peak (120W RMS) 6.5" Reference Series 2 Way Coaxial 3-ohm Speakers

3
-20.01%

$119.95

List price $149.95

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99


Best selling similar products

VADM4v2 small

NVX VADM4 v2 (VADM4v2)

• 80 watts x 4 channel @ 4 ohm
• 125 watts x 4 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(41)

$209.99

List price $239.99

NDA6004 small

NVX NDA6004

• 100 watts x 4 channel @ 4 ohm
• 160 watts x 4 channel @ 2 ohm
• Bridged: 320 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(14)

$159.99

List price $215.99

VAD10004v2 small

NVX VAD10004 v2 (VAD10004v2)

• 150 watts x 4 channel @ 4 ohm
• 250 watts x 4 channel @ 2 ohm
• Bridged: 500 watts x 2 channel @ 4 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(25)

$279.99

List price $335.99

RD400/4 small

JL Audio RD400/4

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 400 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(28)

$304.99

List price $379.99

MFA 4.220 small

Deaf Bonce MFA 4.220

• 220 watts x 4 channel @ 4 ohm
• 330 watts x 4 channel @ 2 ohm
• Bridged: 660 watts x 2 channel @ 4 ohm
• Total RMS Power: 1320 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$289.90

List price $289.90

JD400/4 small

JL Audio JD400/4

• 75 watts x 4 channel @ 4 ohm
• 100 watts x 4 channel @ 2 ohm
• Bridged: 200 watts x 2 channel @ 4 ohm
• Total RMS Power: 400 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(34)

$299.99

List price $299.99

MFA 4.180 small

Deaf Bonce MFA 4.180

• 180 watts x 4 channel @ 4 ohm
• 270 watts x 4 channel @ 2 ohm
• Bridged: 540 watts x 2 channel @ 4 ohm
• Total RMS Power: 1080 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$259.90

List price $259.90

MVPA4 small

NVX MVPA4

• 100 watts x 4 channel @ 4 ohm
• 150 watts x 4 channel @ 2 ohm
• Bridged: 300 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(70)

$279.99

List price $383.99

MDX2000.4 2 Ohm small

PRV Audio MDX2000.4 2 Ohm

• 330 watts x 4 channel @ 4 ohm
• 500 watts x 4 channel @ 2 ohm
• Bridged: 1000 watts x 2 channel @ 4 ohm
• Total RMS Power: 2000 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$219.91

List price $274.89

AP200/4BT small

JL Audio AP200/4BT

• 40 watts x 4 channel @ 4 ohm
• 50 watts x 4 channel @ 2 ohm
• Bridged: 100 watts x 4 channel @ 4 ohm
• Total RMS Power: 200 watts
• Class D 2 ohm Stable 4-Channel Amplifier

$549.99

List price $659.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
75 watts x 4 channel
RMS Power @ 2 ohms
150 watts x 4 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
300 watts x 2 channel
Amplifier Specifications
Number of Channels
4-Channel
Total RMS Power Output
600 watts
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
1 ohm
THD at Rated RMS Power
>0.2%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Signal-to-Noise Ratio
>100 dB
Bass Boost
Optional Accessory Required
Fuse Rating
120A External Fuse Required

Item Details


Manufacturer:

Model Number:

X604

Weight:

12.00lbs

Internal SKU:

x604

Internal Product ID:

3042

Product and How-to Videos


Customer Ratings & Reviews


** BELOW COST!! ** Xtant X604 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

Best SQ amp!!!!!

I am the one that bought the last one in stock!!!!! I am also proud to say that I have been using Xtant amps for years!!! I had an old 302a and upgraded to this beast. There is a lot of work configuring the amp at first but, once it is configured it runs like a champ!!!! This amp is so modular there are countless ways to configure it and can be used with a very large variety of speakers!!!!! On another note it looks great next to my Xtant 1001 amp!!!!

By Jester on June 7, 2011

5 found this helpful
