Audiobahn A2002V

400W Max, Intake Series 2-Channel Amplifier

Audiobahn
Shop all Audiobahn
Product videos
highlight-star-icon

Class A/B Amplifier • Bridgeable • 400W Max • MOSFET power supply • 4 ohm: 200 watts x 1 chan. • 2 ohm: 100 watts x 2 chan. • Various Protection: thermal, short circuit, overload, & DC offset

Learn more about the a2002v

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

a2002j thumbnail

Audiobahn A2002J

OUR PRICE: $99.99

View item

Loading...
70-7903 main

Metra 70-7903 Wiring Harness

Install a new car stereo in select 2001-2021 vehicles from Mazda, Fiat

18
REF687F main

Infinity REF687F (INFSPKRF687FUS)

360W Peak (120W RMS) 6x8" Reference Series 2-Way Coaxial 3-ohm Speakers

1
-18.76%

$129.95

List price $159.95

Product Highlights


Class A/B Amplifier • Bridgeable • 400W Max • MOSFET power supply • 4 ohm: 200 watts x 1 chan. • 2 ohm: 100 watts x 2 chan. • Various Protection: thermal, short circuit, overload, & DC offset

Description


The new Intake series amplifiers are Audiobahn's latest line of full-throttle beauties. Each amp is equipped with an air induction cooling fan to keep the unit running cool for hours. New this year is the on-board, cobalt blue digital voltmeter display which adds more style to already fabulous looking amplifier. If you want to add even more control, an optional remote bass control and remote-mount volt-meter display module are available separately. As always, the Intake amplifiers provide both performance and customization to your sounds.

Key Features:

  • 400W Max , Intake Series 2-Channel Amplifier
  • RMS Power Output:
    • 50 watts x 2 chan. @ 4 ohm
    • 100 watts x 2 chan. @ 2 ohm
    • 200 watts x 1 chan. @ 4 ohm Bridged
  • Max Power Output: 400 watts @ 2 ohm
  • Class A/B MOSFET Circuitry
  • PWM MOSFET Power Supply
  • Non-regulated Power Supply
  • Semi-double Sided Glass Epoxy Circuit Board
  • 4-way Protection Circuitry: Thermal, Short Circuit, Overload and DC Offset
  • Air Induction Cooling Fan
  • Soft Start Circuitry
  • Cobalt Blue Illumination
  • Speaker level (high-level) inputs
  • Preamp outputs
  • Nickel-Plated Block Terminals
  • Bass Boost Control: ON/OFF
  • Optional Remote Bass Control (Audiobahn ABR100T VERSION 2 sold separately)
  • Digital volt-meter display on amplifier and the ability to have an optional Remote-mount Digital Volt-meter display (Audiobahn ADM100T VERSION 2 sold separately)
  • Variable Low-Pass Crossover: 50-120Hz
  • Variable High-Pass Crossover: 50-750Hz
  • Signal-to-Noise Ratio: 100dB
  • Frequency Response: 10Hz-40kHz
  • Variable Subsonic Filter: 20-50Hz
  • THD: 0.02%
  • Input Sensitivity: 200mV-8V
  • Dimensions: 6-13/16"L x 11-1/16"W x 2-1/8"H
  • 10- or 8-gauge power and ground leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
  • 1-year SonicElectronix.com warranty

Product history:

Audiobahn A2002J thumbnail
(newest, current model)
Audiobahn A2002V thumbnail
(previous model, replaced by Audiobahn A2002J)
Audiobahn A2002T thumbnail
(previous model, replaced by Audiobahn A2002V)
