Name: SoundStorm EV2.200 R/B
Brand: Sound Storm Labs (SSL)
SKU: LS-ev2200-RB
Price: 34.99 USD
Availability: Discontinued

by Sound Storm Labs (SSL)

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

SoundStorm EV2.200 R/B Image 1 — SoundStorm EV2.200 R/B

SoundStorm EV2.200 R/B Image 2 — SoundStorm EV2.200 R/B

SoundStorm EV2.200 R/B Image 3 — SoundStorm EV2.200 R/B

SoundStorm EV2.200 R/B Image 4 — SoundStorm EV2.200 R/B

SoundStorm EV2.200 R/B Image 5 — SoundStorm EV2.200 R/B

SoundStorm EV2.200 R/B Image 6 — SoundStorm EV2.200 R/B

Product videos

Product highlights

Evolution Series Two-Channel Class AB Car Amplifier • 4 ohm: 50 watts x 2 chan. • Max Bridged, 4 ohm: 200 watts x 1 chan. • Power and protection LED indicators

Learn more about the LS-ev2200-RB

Product Highlights

Evolution Series Two-Channel Class AB Car Amplifier • 4 ohm: 50 watts x 2 chan. • Max Bridged, 4 ohm: 200 watts x 1 chan. • Power and protection LED indicators

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

Amplifier Features:

Evolution Series Two-Channel Class AB Car Amplifier
RMS Power Rating:
- 4 ohm: 50 watts x 2 chan.
Max power output:
- 4 ohm: 100 watts x 2 chan.
- Bridged, 4 ohm: 200 watts x 1 chan.
MOSFET PWM (Pulse Width Modulated) power supply)
Power and protection LED indicators
Variable tuned bass EQ (0-18 dB bass boost)
4 Ohm stable
2/1 channel monoblock operation
Selectable input sensitivity (100mV-2V or 2V-8V)
Thermal and speaker short protection
Soft turn-on circuit
Remote turn-on/turn-off circuit
Variable input gain control
Dark gray anodized heatsink
Large aluminum heatsink for excellent heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Variable low-pass filter (45-90 Hz, 12 dB/octave)
Variable high-pass filter (120-1,000 Hz, 12 dB/octave)
Frequency response: 12-22,000 Hz
Dimensions: 10"D x 16"W x 2-3/8"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Authorized Internet Dealer
1-year Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

50 watts x 2 channel

Bridged RMS Power

100 watts x 1 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

2-Channel

Total Peak Power Output

200 watts

Total RMS Power Output

100 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

4 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

.01%

Speaker Level Inputs

Yes

Preamp Outputs

Built-in Crossover

Low-Pass (LP)

Signal-to-Noise Ratio

90 dB

Remote bass/level controller

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
