Name: JL Audio XDM800/8
Brand: JL Audio
SKU: xdm8008
Price: 1099.99 USD
Availability: InStock
Rating: 5.0000 (3 reviews)

Shop all JL Audio

by JL Audio

About
FAQ
Similar Products
Specs & Details
Product Videos
Reviews
Add-ons
Related Products
Recently Viewed
Related Searches

JL Audio XDM800/8 Image 1 — JL Audio XDM800/8

JL Audio XDM800/8 Image 2 — JL Audio XDM800/8

JL Audio XDM800/8 Image 3 — JL Audio XDM800/8

JL Audio XDM800/8 Image 4 — JL Audio XDM800/8

JL Audio XDM800/8 Image 5 — JL Audio XDM800/8

JL Audio XDM800/8 Image 6 — JL Audio XDM800/8

JL Audio XDM800/8 Image 7 — JL Audio XDM800/8

Product videos

Product highlights

• 75 watts x 8 channel @ 4 ohm
• 100 watts x 8 channel @ 2 ohm
• Bridged: 200 watts x 4 channel @ 4 ohm
• Total RMS Power: 800 watts
• Class D 2 ohm Stable 8-Channel-Channel Amplifier

Learn more about the xdm8008

Universal – fits most vehicles.

Similar items | Update vehicle | Vehicle store

$1099.99

with warranty

Starting at $69/mo with

Free shipping in USA. Provide zip for delivery date.

VIP Product Get $110.00 in rewards to spend later

Quantity Qty

In Stock

Brand new

Additional conditions

Open Box, Great $934.99

Popular alternative

NVX VAD22008 v2 (VAD22008v2) 2200W RMS Class D V-Series 8-Channel Car, Marine and Powersports Amplifier

(2)

$399.99 $539.99

Product Highlights

• 75 watts x 8 channel @ 4 ohm
• 100 watts x 8 channel @ 2 ohm
• Bridged: 200 watts x 4 channel @ 4 ohm
• Total RMS Power: 800 watts
• Class D 2 ohm Stable 8-Channel-Channel Amplifier

Description

Authorized dealer

JL Audio XDM800/8

The ultra-versatile XDM800/8 delivers eight channels of crystal-clear, full-range power and is capable of delivering a whopping 100 watts to each of its channels @ 2 ohms (14.4V, 1% THD). The technology that makes this much power possible in such a compact chassis is our advanced NexD™ high-speed switching design, which permits full bandwidth Class D operation with extremely low distortion and remarkable efficiency. Suitable for car or boat installations, the XDM800/8 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades.

Product Details:

XDM Series Class D 2 ohm Stable 8-Channel Amplifier
RMS Power Rating:

4 ohm: 75 watts x 8 channel
2 ohm: 100 watts x 8 channel
Bridged: 200 watts x 4 channel @ 4 ohm / 150 watts x 4 channels @ 8 ohm

Total power output: 800 watts
LED Power/Protect Light
Wired bass level remote control with optional JL Audio HD-RLC or JL Audio MHD-RLC
Speaker-level (high-level) inputs (Requires adapter like the JL Audio XD-CLRAIC2-SW)
Protection Circuitry with Status LED
NextD switching amp technology
Differential-balanced inputs help eliminate noise
Weather-resistant chassis: black powder-coat finish, gasketed control cover, stainless steel hardware
Input sensitivity:

Low level: 200mV - 4 volts

Frequency Response: 12 - 22000 Hz
Total Harmonic Distortion (THD): <1%
Signal to Noise Ratio: >104 dB dB
Variable high-pass filter: 50 - 500 Hz
Variable low-pass filter: 50 - 500 Hz
Fuse Rating: 80A
4 AWG gauge amplifier wiring kit is recommended for installation
Dimensions: 14.73" L x 7.09" W x 2.05" H
Authorized Internet Dealer
3 Year Manufacturer's Warranty
MFR #: XDM800/8

Product history:

	JL Audio M800/8v2 (newest, current model)
	JL Audio XDM800/8 (previous model, replaced by JL Audio M800/8v2)
	JL Audio XD800/8v2 (previous model, replaced by JL Audio XDM800/8)

Frequently Asked Questions (FAQ)

My speakers are "hissing" even when the volume is low. How do I fix this?

This is likely "Gain Hiss." Check the "Input Voltage" switch. If using RCA cables from an aftermarket radio, set it to "Low." If using factory speaker wires, set it to "High." Improper settings force the amp to amplify floor noise.

Can I bridge this 8-channel amp to power a 4-speaker high-power system?

Yes. You can bridge any pair (1/2, 3/4, etc.) to get 200W x 4 at 4 ohms. Connect the speaker (+) to the left channel (+) and the speaker (-) to the right channel (-). Note: Bridged channels are not stable at 2 ohms.

The amp turns on but I have no sound on channels 7 & 8. What’s wrong?

Check the "Input Mode" switch. If you only have 2 or 4 RCA cables connected, ensure the switch is set to "2 Ch." or "4 Ch." This internally routes the signal to all 8 channels so you don't need Y-adapters.

Why does the "Status" light turn Red and the sound cut out at high volume?

This is "Low-Voltage Protection." The XDM800/8 draws significant current. Ensure you are using 4-gauge 100% Copper (OFC) wire. If your ground is to a thin or painted metal surface, the voltage will drop and trigger a shutdown.

Can I use this in a boat? It says "Marine" but also "Car."

Yes. The "XDM" series is dual-purpose. It features marine-grade coated circuit boards to prevent corrosion from humidity. However, it is not waterproof—it must be mounted in a dry location away from direct water spray.

How do I set the "Filter Frequency" for my door speakers?

Set the "Filter Mode" to HP (High-Pass). Turn the dial to approximately 80Hz. This protects your 6.5" speakers from deep bass frequencies that cause distortion and potential damage at high volumes.

I’m using a Remote Level Control (HD-RLC), but it only affects some speakers. What to do?

The HD-RLC knob (sold separately) only controls the levels for the specific channel bank it is assigned to via the "Remote Level" switch. Ensure the switch for each channel pair you want to control is toggled to "On."

My factory radio doesn't have a "Remote" wire. How do I turn the amp on?

The XDM800/8 features Signal Sensing. Set the "Turn-on Mode" switch to "Offset" (for factory head units) or "Signal" (for standard audio). This wakes the amp up automatically when it detects music on the input wires.
