Pioneer GM-A3602

400W Peak (180W RMS) 2-Channel A Series Bridgeable Class AB 2-Ohm Stable Car Amplifier

Pioneer
Shop all Pioneer
Product videos
highlight-star-icon

• RMS: 60W x 2 @ 4 ohm, 90W x 2 @ 2 ohm
• Total Peak Power: 400W
• CEA-2006 Compliant
• Dimensions: 9-1/2"W x 7"L x 2-1/2"H

Learn more about the gma3602

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

gma3702 thumbnail

Pioneer GM-A3702

OUR PRICE: $89.99

View item
NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
72-7800 main

Metra 72-7800

Install New Speakers in select 1990-2024 vehicles from Honda, Acura, Isuzu

90
-33.36%

$9.99

List price $14.99

70-1721 main

Metra 70-1721 Wiring Harness

Install a new car stereo in select 1998-2013 vehicles from Honda, Suzuki, Acura

27
99-7814 main

Metra 99-7814

Single DIN or Double DIN Stereo Dash Kit for select 1988-2006 vehicles from Honda, Acura, Isuzu

4
-12.50%

$27.99

List price $31.99

99-7898 main

Metra 99-7898 Dash Kit

Install a new Single-DIN car stereo in select 1990-2006 vehicles from Honda, Acura, Isuzu

14
-11.77%

$29.99

List price $33.99

HonK831 main

American International HonK831

Double DIN Stereo Dash Kit for select 1988-2006 vehicles from Honda, Acura, Isuzu

4
-70.62%

$9.99

List price $34.00

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

XBAF65 main

NVX XBAF65

Universal 6.5" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

117
-37.15%

$21.99

List price $34.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Product Highlights


• RMS: 60W x 2 @ 4 ohm, 90W x 2 @ 2 ohm
• Total Peak Power: 400W
• CEA-2006 Compliant
• Dimensions: 9-1/2"W x 7"L x 2-1/2"H

Description


Pioneer brand icon

Authorized dealer



General Features:

  • Pioneer A-Series GM-A3602
  • Class-AB FullRange 2-Ohm Stable 2-Channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 60 watts x 2 chan.
    • 2 ohm: 90 watts x 2 chan.
    • Bridged, 4 ohm: 180 watts x 1 chan.
  • Max power output: 400 watts.
  • CEA-2006 Compliant Amplifier
  • Pulse Width Modulated MOSFET power supply
  • Balanced Isolator Input Circuit
  • LED power (on) and protect (off) indicators
  • Soft start turn-on
  • 2 or mono channel operation
  • Speaker-level (high-level) inputs with Signal Sensing Turn-on
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heat-sink for extreme heat dissipation
  • Input sensitivity:
    • Low level: 300mV - 6.5V
    • High level: 3V - 26V
  • Frequency Response: 10 - 70,000 Hz
  • Total Harmonic Distortion (THD): <0.05%
  • Signal to Noise Ration: >95 dB
  • Selectable Low-Pass Crossover at 80Hz, 12 dB/octave
  • Fuse Rating: 25A x 1
  • 4 - 8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
  • Dimensions: 9-1/2"W x 7"L x 2-1/2"H
  • 1-year Sonic Electronix Warranty

Product history:

Pioneer GM-A3702 thumbnail
(newest, current model)
Pioneer GM-A3602 thumbnail
(previous model, replaced by Pioneer GM-A3702)
Pioneer GM-3500T thumbnail
(previous model, replaced by Pioneer GM-A3602)
Pioneer GM-3400T thumbnail
(previous model, replaced by Pioneer GM-3500T)
Pioneer GM-3300T thumbnail
(previous model, replaced by Pioneer GM-3400T)

Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

59
-19.05%

$339.99

List price $420.00

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

214
-9.16%

$109.00

List price $119.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

72
-10.53%

$84.99

List price $94.99

Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
60 watts x 2 channel
RMS Power @ 2 ohms
90 watts x 2 channel
Bridged RMS Power
180 watts x 1 channel
Power Specifications - Full Range Channels
Peak Power @ 4 ohms
120 watts x 2 channel
Peak Power @ 2 ohms
200 watts x 2 channel
Bridged Peak/Max Power
400 watts x 1 channel
Amplifier Specifications
Series
GM Series
Amplifier Class
A/B
Number of Channels
2-Channel
Total Peak Power Output
400 watts
Total RMS Power Output
180 watts
Maximum Input Gauge Size
Any Gauge with use of Spade Terminal AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.05%
Speaker Level Inputs
Yes
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
Full (AP)
Low-Pass Crossover Frequency
80Hz
Signal-to-Noise Ratio
95 dB
Bass Boost
N/A
Remote bass/level controller
No
Fuse Rating
25A x 1
Strappable
No
Sonic Certified Amplifier
Not Tested
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

GM-A3602

Weight:

3.50lbs

Internal SKU:

gma3602

Internal Product ID:

74608

Product and How-to Videos


  • Pioneer GM Series Car Amplifiers
  • How To Install an Amplifier: Car Amplifier Basics Part 2

Customer Ratings & Reviews


Pioneer GM-A3602 thumbnail image

5 star
74%
4 star
26%
3 star
0%
2 star
0%
1 star
0%



Durability
4.7
Value
4.7
Features
4.4
Design
4.6
Usability
4.9

Customer Reviews

Sort by:

Loading...

Faithful Pioneer Enthusiast

Always been faithful to Pioneer auto audio, due to the great sound results I had though many years and systems I installed in my vehicles. This amp is one of two I just installed in my GMC Sierra pickup truck to replace the crappy factory Bose system. The results, as always, are great sound definition and that extra punch of power I always liked about Pioneer amps. My truck sounds like a concert hall now...

By Jose on September 13, 2014

46 found this helpful


little amp but powerfull

The amp its great!! Is little but powerfull
If you want something small and powerfull
(150 watts rms one channel). It sounds great for a little amp.

By zito on September 20, 2014

42 found this helpful


Lots of clean power

This amp gives lots of clean power on demand. Pushing a small 8" open air sub in the rear deck and sounds great. Perfect match for the application. Very good choice.

By John on April 2, 2015

40 found this helpful


Small and perfect

I have a 12" sub and 2 6.5" speakers. I chose to use the 6.5's in my 95 isuzu rodeo as little subs instead of the 12" to save on space. The speakers are rated at 50 watts rms so this amp is perfect for them. My 95 rodeo has 4 4" speakers so there's very little bass coming out of them and I do mean very little. By this amp putting out 10 more rms watts than the speakers are rated, it helps the amp run cooler because the gain is set arount 2-3v whitch is low. I just wanted to add a little bass to balance the sound out. This is probably the most cost efficient and reliable amp you will find within this price range.

Perfect little amp for my setup. I would recommend this amp to anybody that wants to add a little clarity or bass to a small setup.

By cra2006 on March 31, 2015

37 found this helpful


Well worth it

The following review is for a previous version (GM-3500T).

Gives great power to my RF 6x9s. Easy to set up and good power from something small. easy to hide in the car.

By chris on March 12, 2013

33 found this helpful


great amp

The following review is for a previous version (GM-3500T).

Got this amp awhile ago and its still running great. Works very well with my single 10" audiobahn sub. Clean sound and pretty powerful for the size.

By jared on May 30, 2013

30 found this helpful


Great amp

The following review is for a previous version (GM-3500T).

This amp is really great for the price. It doesn't get very warm at all, even when playing music really loudly. I have this hooked up to a pair of Rockford Fosgate P1692s and it sounds really really great. As far as I can tell, the only unwanted noise coming out of this amp is from my iPhone's mediocre headphone jack. This amp has really clean output. I haven't come across any problems with it so far. The terminals are pretty easy to use. I didn't have to adjust the gain at all for my use. Since this is a CEA compliant amp, you get exactly what you pay for. It is quite loud, although I could foresee wanting a more powerful amp. I have not tried the bridging feature.

By beak90 on February 12, 2012

29 found this helpful


Good Amp!

The following review is for a previous version (GM-3500T).

Very good amp, I have this connected to my speakers 6 1/2 on my honda civic, clean sound and never got hot.

By Carlos on April 12, 2012

29 found this helpful


Great Company

The following review is for a previous version (GM-3300T).

pioneer is one of the best audio/video companies there is. This is a great price for an amazing amp!

By Nick on September 11, 2008

27 found this helpful


WOW!

The following review is for a previous version (GM-3300T).

This Pioneer GM-3300T are connected to 2 pioneer 6x9's and man they slap.
really good, combination.
I like it also because it fit right under my car seat. great.

By Cesar on July 13, 2007

26 found this helpful




GM-5500T small

Pioneer GM-5500T

820W Max 2-Channel GM Series Car Amplifier w/ High-Level Speaker Inputs

(43)

$109.95

List price $199.95

GM-A5702 small

Pioneer GM-A5702

1000W Peak (480W RMS) 2-Channel Bridgeable Class AB 2-Ohm Stable Amplifier

(56)

$99.99

List price $180.00

SWS-1243D small

Alpine SWS-1243D

12" Dual 4 ohm Type-S Series Car Subwoofer

(29)

$79.95

List price $169.99

XM-2002GTW small

Sony XM-2002GTW

1200W Max, 2/1 Channel Amplifier

(8)

$129.99

List price $199.99

Related Searches


Save up to 10 different vehicles in your garage
Vehicle
Store
Delete

2000 Honda CR-V

1959 Buick Electra

2000 Jaguar XK8

1982 Toyota Celica Supra

2013 Chevrolet Corvette

2018 Nissan Frontier

2012 Mercedes-Benz E-Class

2015 Mercedes-Benz Sprinter

2018 Toyota Camry

2019 Audi TT Quattro

Vehicle
Store
Delete

2000 Harley Davidson FLHT/I Electra Glide Standard

1960 Harley Davidson FL

Vehicle
Store
Delete

2016 Can-Am Commander Max 1000 LTD

2023 Can-Am Maverick Trail DPS

2025 Can-Am Defender DPS HD9

Add vehicle Clear all vehicles
Where to find vehicle info
Are you sure you want to clear your garage?
This action cannot be undone. Confirm
This page was not designed for products.
If you continue, you will be redirected to a category customized for your vehicle. Continue
Loading...
Identify your vehicle and submodel details
  • Owner's manual
  • Vehicle's insurance card
  • Vehicle registration
  • Vehicle produced after 2005: Inside driver's side door
  • Vehicle produced before 2005: Rear passenger doorjamb, glove box, center console, or engine compartment
Car Info Side Door Icon
Vehicle Registration Icon
Vehicle Insurance Icon

Modern vehicles often require specific brackets, wiring harnesses, and mounting solutions. A fit guide ensures:

  • You see only parts engineered for your exact vehicle
  • You avoid incompatible radios, speakers, or wiring
  • Installation is smoother, faster, and frustration-free
  • You get the correct accessories the first time

Whether you're replacing a factory stereo or upgrading your entire audio system, the Fit Finder eliminates uncertainty.
